Control Box Assembly

Ref.
No:

Part
No:

Description:

Ref.
No:

Part
No:

Description:

Image 1:

TRANSFORMER 208/230, 24V

B1141643

61

CONTACTOR 25 AMP, 1P, 24V (M1, M2, M3)

CONT1P025024VS

71

CONTACTOR 30 AMP, 1P, 24V (M4, M5)

CONT1P030024VS

71

CAPACITOR 5/35/440V (M1)

CAP050350440RSS

91

CAPACITOR 5/40/440V (M2)

CAP050400440RT

91

CAPACITOR 5/45/440V (M3, M4, M5)

CAP050450440RT

91

CAPACITOR STRAP

20520901

191

WIRE HARNESS, ELECTRIC HEAT

0259G00021

331

Expanded Model Nomenclature

M1 - GPC1424H41AB

M2 - GPC1430H41AB

M3 - GPC1436H41AB

M4 - GPC1442H41AB

M5 - GPC1448H41AB

11

RP-622A
