Cabinet Assembly

Ref.
No:

Part
No:

Description:

Ref.
No:

Part
No:

Description:

Image 1:

INSULATED ASSY, DUCT PANEL 27.5" (M1, M2,
M3)

0270G00008PS

11

INSULATED ASSY, DUCT PANEL 32.5" (M4)

0270G00009PS

11

INSULATED ASSY, DUCT PANEL 36" (M5)

0270G00010PS

11

INSULATED ASSY, CORNER PANEL 27.5" (M1,
M2, M3)

0270G00011PS

21

INSULATED ASSY, CORNER PANEL 32.5" (M4)

0270G00012PS

21

INSULATED ASSY, CORNER PANEL 36" (M5)

0270G00013PS

21

CORNER POST 27.5" (M1, M2, M3)

0121G00047PDGS

31

CORNER POST 32.5" (M4)

0121G00048PDGS

31

CORNER POST 36" (M5)

0121G00082PDG

31

INSULATED ASSY, BLOWER DOOR 27.5" (M1, M2,
M3)

0270G00113S

41

INSULATED ASSY, BLOWER DOOR 32.5" (M4)

0270G00114S

41

INSULATED ASSY, BLOWER DOOR 36" (M5)

0270G00115S

41

EXTERNAL CONTROL BOX PANEL

0121G00276DGS

51

LOUVERED PANEL 4 BANK 27.5" (M1, M2, M3)

0121G00069PDGS

61

LOUVERED PANEL 4 BANK 32.5" (M4)

0121G00070PDG

61

LOUVERED PANEL 4 BANK 36" (M5)

0121G00090PDGS

61

LOUVERED PANEL 5 BANK 27.5" (M1, M2, M3)

0121G00072PDG

71

LOUVERED PANEL 5 BANK 32.5" (M4)

0121G00073PDGS

71

LOUVERED PANEL 5 BANK 36" (M5)

0121G00091PDGS

71

EVAP PANEL INSUL ASSY-27.5" (M1, M2, M3)

0270G00017P

81

EVAP PANEL INSUL ASSY-32.5" (M4)

0270G00018P

81

EVAP PANEL INSUL ASSY-36" (M5)

0270G00019P

81

GROMMET / HS .62 - .45

B1392011

91

COMPRESSOR PANEL 13.68" X 27.50" (M1, M2,
M3)

0121G00062PDGS

101

COMPRESSOR PANEL 8.75" X 32.50" (M4)

0121G00060PDGS

101

COMPRESSOR PANEL 8.75" X 36" (M5)

0121G00087PDGS

101

LOUVERED PANEL 4 BANK 27.5" (M1, M2, M3)

0121G00069PDGS

111

LOUVERED PANEL 5 BANK 32.5" (M4)

0121G00073PDGS

111

LOUVERED PANEL 5 BANK 36" (M5)

0121G00091PDGS

111

Expanded Model Nomenclature

M1 - GPC1424H41AB

M2 - GPC1430H41AB

M3 - GPC1436H41AB

M4 - GPC1442H41AB

M5 - GPC1448H41AB
