Magnum DS80F & DS80C Dual-speed Stackable Hubs Installation and User Guide (05/04)
4
Table of Contents Page
1.0 SPECIFICATIONS .................................................................................... 6
1.1 Technical Specifications .......................................................................... 6
1.2 Ordering Information ............................................................................... 8
2.0 INTRODUCTION ..................................................................................... 9
2.1 Inspecting the Package and Product .......................................................... 9
2.2 Product Description - General ............................................................ 10
2.2.1 DS80F chassis with fiber ST or SC (mm or sgl. mode) connector ........... 11
2.2.2 Magnum DS80C chassis with all RJ-45 Copper ports ........................ 11
2.2.3 10 / 100 Speed Auto-sensing .......................................................... 12
2.3 Up-link Port 1SW for Cascading ............................................................. 12
2.4 Fiber port for DS80F – Series ................................................................. 12
2.5 Features and Benefits ............................................................................ 14
2.6 Applications ......................................................................................... 15
3.0 INSTALLATION ..................................................................................... 17
3.1 Locating Magnum DS80F & DS80C Dual-Speed Hubs ............................. 17
3.1.1 Table-Top or Shelf Mounting ......................................................... 17
3.1.2 Wall (or vertical surface) mounting ................................................. 17
3.2 Connecting Ethernet Media .................................................................... 18
3.2.1 Twisted Pair (RJ-45, CAT 3 or CAT 5, Unshielded or Shielded) ........... 18
3.2.2 Connecting Fiber Optic ST-type, “twist-lock” .................................. 18
3.2.3 Connecting Fiber Optic SC-type, "Snap-In" ..................................... 19
3.2.4 Connecting Single-Mode Fiber Optic .............................................. 19
3.2.5 Power Budget Calculations for DS80F Fiber Media .......................... 19
3.2.6 Connections to NICs which support Auto-Negotiation, RJ-45 ports .... 20
3.3 Powering the Magnum DS80F and DS80C .............................................. 21
4.0 T he function and operation of the Magnum DS80F and DS80C hubs. ....... 22
4.1 Dual-speed functionality, and switching............................................ 22
4.2 Auto-negotiation and speed-sensing ........................................................ 23
4.3 Full or Half - Duplex, manual switch selection for DS80F Models ............. 23
4.4 Full Fixed or Auto-Negotiation, manual switch selection for DS80C Models 23
4.5 LED’s ............................................................................................... 24
4.6 Up-link Port .......................................................................................... 24
4.7 Use with Media Converters .................................................................... 24
5.0 TROUBLESHOOTING ........................................................................... 25
5.1 Before Calling for Assistance ................................................................. 25
5.2 When Calling for Assistance .................................................................. 26
5.3 Return Material Authorization (RMA) Procedure ............................. 26
5.4 Shipping and Packaging Information ....................................................... 27
APPENDIX A: WARRANTY INFORMATION .................................................. 27
Revisions
04/05: Minor update on Caution for F-H switch
