-68-
Model G9901/G9902/G9903 Milling Machine
Model G9901/G9902 Drive Assembly
Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
301
P9902301
DRAWBAR 24-3/16
343-5 PN01M
HEX NUT M6-1
302
P9901302
DRAWBAR SPACER
343-6 PSB24M
CAP SCREW M5-.8 X 16
303
P9901204
SPECIAL NUT M33 X 1.5
343-7 PLW01M
LOCK WASHER 5MM
304
P9901304
SPECIAL NUT M60 X 1.5
343-8 PRP76M
ROLL PIN 4 X 16
305
P60072RS
BALL BEARING 6007-2RS
343-9 P9901343-9
HOLDER M6-1 X 20
306
P9901306
SPACER
344
PW06M
FLAT WASHER 12MM
307
P9901307
SPACER
344-1 P9901344-1
THICK HEX NUT M12 X 1.75
308
P60072RS
BALL BEARING 6007-2RS
345
P9901345
HANDLE
309
P9901309
SPRING
345-1 P9901345-1
HANDLE KNOB
311
P9901311
BEARING BRACKET
346
PSS03M
SET SCREW M6-1 X 8
314
PSB58M
CAP SCREW M8-1.25 X 12
347
P9901347
MOTOR PULLY
315
P9901315
SPRING
348
P9901348
SPECIAL WASHER
316
PRP11M
ROLL PIN 2.5 X 16
349
PR88M
INT RETAINING RING 8MM
317
P9901317
BRAKE LOCK STUD
350
PB07M
HEX BOLT M8-1.25 X 25
318
P9901318
BRAKE SHOE
351
P9901351
COTTON CORE TYPE OIL CAP
319
P9901319
SPINDLE PULLEY
352
P9901352
OIL CUP ADAPTER
320
P9901320
COUPLING SHAFT
353
P9901353
COPPER TUBE
321
PK149M
KEY 8 X 8 X 25
354
PS68M
PHLP HD SCR M6-1 X 10
322
PVA32
V-BELT A-32 4L320
355
P9901355
COVER
323
P9901323
RIBBED TIMING BELT
356
PK40M
KEY 8 X 8 X 16
324
P9901324
PULLEY FLANGE
357
P9901357
WORM COUPLING SHAFT
325
P9901325
TIMING BELT PULLEY
358
P9901358
BULL GEAR
326
P9901326
TABBED LOCK WASHER 16MM
359
PSB01M
CAP SCREW M6-1 X 16
327
PSS31M
SET SCREW M5-.8 X 8
360
P9901360
THREADED CONICAL PIN 8 X 25
328
P9901328
FLANGE NUT M16-1.5
361
P9901361
BEARING BRACKET
329
P9901329
HANDLE KNOB
362
P6203
BALL BEARING 6203ZZ
330
PSS81M
SET SCREW M3-.5 X 5
363
PR23M
INT RETAINING RING 40MM
331
P9901331
HANDLE HUB
364
P9901364
SPLINE SHAFT
331-1 P9901331-1
HANDLE
365
P9901365
WOODRUFF KEY 5 X 16
332
P9901332
PIN
366
P9901366
PINION
333
P9901333
BUSHING
367
P6203
BALL BEARING 6203ZZ
334
P9901334
SPECIAL WASHER
368
P9901368
PLUG
335
P9901335
TRANSMISSION COVER PLATE
371
P9901371
THRUST BEARING 40 X 68 X 15
336
P9901336
TAPERED PIN 10 X 30
373
P9901373
TABBED LOCK WASHER 39MM
337
PSB130M
CAP SCREW M10-1.5 X 16
374
P9901374
FLANGE NUT M39-1.5
338
P9901338
MOTOR RING
375
P9901375
COVER
339
P9901339
HANDLE
376
PSB26M
CAP SCREW M6-1 X 12
340
P9901340
HANDLE KNOB
377
P9901377
FLANGE RING SMALL
341
P9901341
STUD M12-1.75 X 35
378
P9901378
FLANGE RING LARGE
342
P9901342
BELT HOUSING
379
P9901379
SHIFTER FORK
343
P9901343
RIGHT BELT COVER
380
PRP16M
ROLL PIN 3 X 25
343-1 P9901343-1
LEFT BELT COVER
381
P9901381
CONNECTING BAR
343-2 P9901343-2
SPRING PLATE
385
P9901385
BRACKET
343-3 P9901343-3
BRACKET
386
PSB03M
CAP SCREW M5-.8 X 8
343-4 PN06M
HEX NUT M5-.8
387
P9901387
SHIM
