Model G9901/G9902/G9903 Milling Machine
-71-
Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 PN01M HEX NUT M6-1 551 P9901551 BEVEL GEAR
502 PLW03M LOCK WASHER 6MM 552 P9901552 BUSHING
503 P9901503 BEVEL GEAR 553 PSS01M SET SCREW M6-1 X 10
504 P9901504 BUSHING 554 PSS03M SET SCREW M6-1 X 8
505 P9901505 BUSHING 555 P9901555 SLIDE ROD
506 PSS31M SET SCREW M5-.8 X 8 556 PRP43M ROLL PIN 3 X 22
507 P9901507 WORM GEAR SPACER 557 P9901557 HOLLOW SHAFT
508 P9901508 WORM GEAR 560 P9901560 SMALL SHAFT
509 P9901509 SHAFT 561 PSS26M SET SCREW M5-.8 X 6
510 PK103M KEY 3 X 3 X 12 562 P9901562 PIN
511 PK98M KEY 3 X 3 X 16 563 P9901563 SLIDE
512 PN03M HEX NUT M8-1.25 564 P9901564 ECCENTRIC WHEEL
513 PW01M FLAT WASHER 8MM 565 P9901565 CLUSTER GEAR COVER
514 PK103M KEY 3 X 3 X 12 566 PSS41M SET SCREW M8-1.25 X 18
515 P9901515 BEVEL GEAR 567 P9903567 COMPRESSION SPRING
516 P9901516 FEED ENGAGE PIN 568 P9901568 STEEL BALL 3/16"
517 P9901517 WORM GEAR SUPPORT 569 PSB24M CAP SCREW M5-.8 X 16
518 P9901518 SHAFT 570 P9901570 DIAL KNOB
519 P9901519 FLANGE 571 PSS26M SET SCREW M5-.8 X 6
520 P9901520 PLUNGER 572 PSS26M SET SCREW M5-.8 X 6
521 P9902521 SPRING 573 PSB78M CAP SCREW M5-.8 X 40
522 PRP42M ROLL PIN 3 X 20 574 P9901574 THREAD PIN
523 P9901523 SHIFTER CRANK 575 P9901575 SLEEVE
524 P9901524 HANDLE KNOB 576 PSS03M SET SCREW M6-1 X 8
525 PSB33M CAP SCREW M5-.8 X 12 577 P9901577 PLUG 4X2
526 PSS03M SET SCREW M6-1 X 8 578 P9901578 SPECIAL NUT M22 X 1.5
527 P9901527 BUSHING 579 P9904379 SPRING
528 P9901528 GEAR 580 P9901580 CLUTCH
529 P9901529 GEAR 581 P9901581 COUPLING SHAFT
530 P9901530 GEAR 582 P9901582 KEY
531 PK150M KEY 3 X 3 X 40 583 PS56M PHLP HD SCR M4-.7 X 16
532 PSS03M SET SCREW M6-1 X 8 584 PLW02M LOCK WASHER 4MM
533 P9901533 BEVEL GEAR SHAFT 585 PSS04M SET SCREW M6-1 X 12
534 PR02M EXT RETAINING RING 14MM 586 PSS04M SET SCREW M6-1 X 12
535 P9901535 BUSHING 587 P9901587 ADJUSTING WASHER
536 P9901536 GEAR 588 P9901588 COMPRESSION SPRING
537 PK96M KEY 3 X 3 X 20 589 P9901589 TOP PIN
538 P9901538 GEAR SHAFT 590 P9901590 SLEEVE
539 PK03M KEY 3 X 3 X 8 591 P9901591 THRUST BEARING 15 X 28 X 9
540 P9901540 GEAR 592 P9901592 FEED WORM GEAR
541 P9901541 BUSHING 593 P9901593 CLUTCH
542 P9901542 BUSHING 594 PRP24M ROLL PIN 5 X 16
543 P9901543 WORM GEAR 595 PRP39M ROLL PIN 4 X 20
544 PSB28M CAP SCREW M6-1 X 15 596 P9901596 CONNECTING ROD
545 PRP02M ROLL PIN 3 X 16 597 P9904397 SPECIAL WASHER 10MM
546 P9901546 BUSHING 598 PR01M EXT RETAINING RING 10MM
547 P9901547 SPECIAL WASHER 599 P9901599 COVER
548 P9901548 SLEEVE 600 PSS91M SET SCREW M6-1 X 14
549 P9901549 BEVEL GEAR 601 PN01M HEX NUT M6-1
550 P9901550 REVERSE CLUTCH 602 PRP03M ROLL PIN 5 X 20
