-72-
Model G9901/G9902/G9903 Milling Machine
REF PART # DESCRIPTION REF PART # DESCRIPTION
603 P9901603 LEVER 651 PR13M EXT RETAINING RING 65MM
604 P9901604 HANDLE 652 P9901652 QUILL LOCK BOLT M8-1.25 X 70
605 P9901605 HANDLE KNOB 653 P9901653 LOCK SLEEVE
606 P9901606 BRACKET 654 P9902654 SPECIAL SCREW M6-1 X 8
607 PSB27 CAP SCREW 5/8-11 X 2-1/2 655 P9901655 T-SLOT BOLT M12-1.75 X 175
608 PSS03M SET SCREW M6-1 X 8 656 P9901656 SLEEVE
609 PK29M KEY 4 X 4 X 8 657 PN09M HEX NUT M12-1.75
610 P9901610 FEED REVERSE KNOB STUD 658 PS17M PHLP HD SCR M4-.7 X 6
611 P9901611 REVERSE KNOB 659 P9901659 SCALE
612 P9901612 PIN 660 PR05M EXT RETAINING RING 15MM
613 P9901613 RETAINING RING 661 P9901661 ADJUSTING NUT
614 P9901568 STEEL BALL 3/16" 662 P9901662 DIAL
615 P9903567 SPRING 663 P9901663 STOP KNOB
616 PSS16M SET SCREW M8-1.25 X 10 664 P9901664 QUILL LEAD SCREW
617 PRP76M ROLL PIN 4 X 16 665 PSB130M CAP SCREW M10-1.5 X 16
618 P9901618 T-ROD 666 P9901666 SHAFT
620 P9901620 SPRING 1.2 X 10 X 25 667 PK34M KEY 5 X 5 X 20
621 P9901621 SHAFT 668 PSS16M SET SCREW M8-1.25 X 10
622 P9901622 BUSHING 669 P9901669 PIN
623 P9901623 BUSHING 670 PRP24M ROLL PIN 5 X 16
624 P9901624 PLUNGER 671 PK34M KEY 5 X 5 X 20
625 P9901625 HANDWHEEL 672 PB136M HEX BOLT M4-.7 X 16
626 P9901626 HANDWHEEL HANDLE 673 P9901673 STOP PLATE
627 P9901627 SPINDLE 674 PSS60M SET SCREW M8-1.25 X 14
628 PSB33M CAP SCREW M5-.8 X 12 675 P6760050 SPRING
629 P9901629 LOCK NUT 676 P9901568 STEEL BALL 3/16"
630 P9901630 LOCK NUT 677 PSS35M SET SCREW M4-.7 X 16
631 P6206-2RS BALL BEARING 6206 2 RS 678 P9901678 HANDLE HUB
632 P9901632 QUILL SKIRT 679 P9901679 BUSHING
633 P9901633 NOSE PIECE 680 P9901680 BUSHING
634 P9901634 SPINDLE DIRT SHIELD 681 P9901681 COILED SPRING
635 P9901635 THRUST BEARING 40 X 60 X 15 682 P9901682 GEAR
636 P9901636 BEARING SLEEVE 683 P9901683 LEVER
637 P9901637 BEARING SLEEVE 684 P9901684 SHAFT
638 P9901635 THRUST BEARING 40 X 60 X 15 685 PSS20M SET SCREW M8-1.25 X 8
639 P9901639 ADJUSTING NUT M39 X 1.5 686 P9901686 WORM GEAR
640 PSS26M SET SCREW M5-.8 X 6 687 PK37M KEY 4 X 4 X 16
641 P9901641 DOG POINT SET SCREW M5-.8 X 6 688 PSS26M SET SCREW M5-.8 X 6
642 P9901642 QUILL 689 P9901689 SHAFT
643 P9901643 OIL SEALER 690 P9902690 HANDLE
644 PN07M HEX NUT M3-.5 691 P9902691 HANDLE KNOB
645 PSS100M SET SCREW M3-.5 X 14 692 P9901692 HEADSTOCK
646 P9901646 FORKED ROD 693 P9901693 OIL CUP ADAPTER
647 P9901647 THREAD PIN 694 P9901694 OIL CUP
648 PSB18M CAP SCREW M4-.7 X 8 695 P9901695 TUBING
649 P9901649 THREADED BUSHING 695-1 P9901695-1 COTTON WIRE
650 P9901650 RETAINING PLATE
