Gianni Industries BTS-486 User Manual

Bts touch exit button, Installation instruction, Fig.a

background image

BTS-100

BTS-115-ANSI,115-S

BTS-400ANSI,300

BTS-85UK

BTS-486

12~24VDC

12~24VDC

12~24VDC

12~24VDC

12~24VDC

30~60mA/12VDC
40~80mA/24VDC

30~50mA/12VDC
40~60mA/24VDC

20~40mA/12VDC
20~50mA/24VDC

60~100mA/12VDC
80~120mA/24VDC

30~60mA/12VDC
40~80mA/24VDC

Com,N/C,N/O

Com,N/C,N/O

Com,N/C,N/O

Com,N/C,N/O

Com,N/C,N/O

3A/30VDC

3A/24VDC

3A/24VDC

3A/24VDC

3A/24VDC

1~30 seconds

1~30 seconds

1~30 seconds

1~30 seconds

1~30 seconds

Green(Relay)

Green(Relay)

Green(Relay)

2x6 levels of LED

-20~+70ºC

-20~+70ºC

-20~+70ºC

-20~+70ºC

-20~+70ºC

N/O,N/C output setting

BTS Touch Exit Button

The BTS touch sensitive exit button has

N.O. and N.C. contact output and can be

connected directly to a electromagnetic lock

or a proximity reader in series (or in parallel).

Fig.A

Copyright © GIANNI Industries,Inc.All rights reserved.
P-MU-BTS Ver.D Published 2011.03.18

1

30 sec.

1

30 sec.

Installation Instruction

Specifications

Wiring Diagram

Mode

Operating Voltage

Current Draw

Relay contact
output

Relay rating

Relay strike time

LED status

Temperature

Other

indication

indicator

2x6 levels of LED

indicator

In Fig.A, BTS controls the fail-safe locking

device directly by series connection. BTS

relay time is door-opening time.

Power
Supply

Power
Supply

Control Device (Outdoor)

Relay output
control

Relay Timer

Relay Timer

BTS Touch Sensitive Switch (Indoor)

BTS Touch Sensitive Switch (Indoor)

Fig.B

Locking Device

(fail-safe)

Locking Device

(fail-secure)

Control Device (Outdoor)

Relay output
control

In Fig.B, BTS controls the fail-secure locking

device directly by parallel connection. BTS

relay time is door-opening time.

Note:
1. Make sure that the power input and relay rating output (3Amp/24VDC) are correct.

2. Make sure that the “+” and “-” wires are connected correctly.

3. The door strike or relay must have a varistor or a diode across the door strike terminals to suppress the

back EMF of the strike. Failure to do so will damage the relay contacts and electronic omponents, or

even burn the controller.
