COPYRIGHT
1996 MERIT INDUSTRIES, INC.
PM0070-0C
MEGATOUCH SUPER IV MANUAL
13
19” UPRIGHT
REF#
QUANTITY
PART NO.
DESCRIPTION
X
1
EC2001
POWER CORD, 120V
X
1
EC2002
POWER CORD, 240V
1
1
HW8711
ANCHOR PLATE FOR CAM LOCK
2
1
HW8716
FLAT LOCK, #564
3
4
HW8960
LEG LEVELER
4
2
MW0044-01
DOOR LOCK PLATE, URTB
5
1
SA3230-01
BEZEL ASSEMBLY
6
1
MW5006-01
SPEAKER COVER
7
1
SA0015-01
HARNESS, MAIN, UNIVERSAL, 19”CAB/URTS
8
1
SA3216-01
AC POWER HARNESS
9
1
EC7526-02
POWER SUPPLY
10
1
TA10004-02
PCA, CPU, VID, 260
11
1
SA3202-04
SHELF ASSEMBLY, TOUCHSCREEN/CRT, 120V
12
1
WD2014-01
PCB MOUNTING SHELF
13
1
SA3210-02
TOUCHSCREEN/CRT ASSEMBLY
14
1
EC9374
CRT, COLOR, 19” CGA
15
1
EC9823
TOUCHSCREEN OVERLAY, 19”
16
1
WD2013-01
CRT MOUNTING SHELF
17
1
MW5003-01
CRT ADJUST, BRACKET, LEFT
18
1
MW5003-02
CRT ADJUST, BRACKET, RIGHT
19
1
SA3206-01
POWER ENTRY, UR 19”, T/S, 120V
19
1
SA3170-01
POWER ENTRY, UR 19”, T/S, 240V
20
1
SA4084
SPEAKER ASSEMBLY
21
1
WD2012-01
CABINET, 19” UPRIGHT TOUCHSCREEN
23
1
SA3209-01
METER/TEST SWITCH BRACKET ASSEMBLY
24
1
EC9840
SMT-3 TOUCHSCREEN CONTROL MODULE
25
1
MW0006-01*
COVER, PCA, 19” URTS/CAB (*240V GAMES ONLY)
26
1
SB0004-02*
ASSY, MOV/ARRESTOR (*240V GAMES ONLY)
27
1
HW0001-01
SAFETY COVER, POWER SUPPLY
