PM0070-0C MEGATOUCH SUPER IV MANUAL 11
MEGATOUCH IV PARTS LISTS
COUNTERTOP
REF # QUANTITY PART NO. DESCRIPTION
X 1 EC2001 POWER CORD, 120V
X 1 EC2002 POWER CORD, 240V
X 2 GL3000-XX DECAL, MEGATOUCH, (-01=RT;-02=LT)
1 1 MW5165-01 MONITOR FILLER PLATE
2 1 MW5167-01 LOCK BRACKET, REAR DOOR
3 2 MW5151-01 MONITOR SUPPORT
4 1 MW5150-01 MAIN CHASSIS
5 1 HW8018-01 RUBBER ANTI-SKID PAD
6 1 HW8993-02 LAZY SUSAN, 12” DIAMETER, 15 DEG STOPS
7 1 HW9001 PLASTIC TUBING
8 1 SA5151-01 TOUCHSCREEN/CRT ASSEMBLY
9 1 EC9359 CRT, COLOR, 14” CGA, WITH FRAME
10 1 EC9824 TOUCHSCREEN OVERLAY
11 2 MW5155-01 LID, RETAINING BRACKET
12 1 MW5159-01 LID, LOCK BRACKET, RIGHT
13 1 MW5159-02 LID, LOCK BRACKET, LEFT
14 1 MW5161-01 REAR DOOR
16 1 MW5164-01 HINGE, REAR DOOR
17 1 HW8713 FLAT LOCK #564 (REAR DOOR)
18 1 WD5171-01 CABINET SIDE, RIGHT
19 1 WD5171-02 CABINET SIDE, LEFT
20 1 EC9154 COUNTER, 12V, FROG EYE MOUNTING
21 1 SA5123-01 AC POWER HARNESS
22 1 SA5131-01 MAIN HARNESS
23 1 HW8953 BEZEL, 13” T/S
24 1 SA4084 4” SPEAKER ASSEMBLY
25 1 EC7526-02 POWER SUPPLY, SW, 11 AMP
26 1 MW5156-01 RETAINING BRACKET, COIN BOX
27 1 TA10004-02 PCA, CPU, VID, 260 TESTED
28 1 EC9840 SMT-3 TOUCHSCREEN CONTROLLER
30 1 HW8741 CIRCULAR LOCK (COIN MECH)
31, 32 1 SA5156-01 CONNECTOR COIN BOX ASSEMBLY
33 1 SA5153-01 COIN BOX ASSEMBLY
34 1 HW8727 LOCK, COIN BOX
35 1 MW5153-01 LID, COIN BOX
36 2 HW4498 THUMB SCREWS, BRASS
37 1 SA5152-XX
POWER ENTRY (POWER ENTRY TYPE DETERMINED BY
LINE CORD REQUIREMENTS)
38 1 SB0004-02* ASSY, MOV/ARRESTOR (*240V GAMES ONLY)
39 1 HW0001-01 SAFETY COVER, POWER SUPPLY
