REF PART # DESCRIPTION REF PART # DESCRIPTION
-24- G1014Z Combination Sander
57 P1014057 SUPPORT 5 ⁄
8
''-11 x 9''
58 P1014058 FOOT
59 P1014059 IDLER ROLLER SHAFT
62B P1014062B ROLLER ADJ BAR
64 P1014064 IDLER ROLLER
65 PCB05 CARRIAGE BOLT 5 ⁄
16
-18 x 3 ⁄
4
''
69 P1014069 MITER BODY
70 P1014070 SCALE
71 P1014071 POWER CORD
77 PAW04M ALLEN WRENCH 4MM
80 PK23M KEY 5 X 5 X 25
81A P1014081A ROCKER PLATE
82A P1014082A LEVER, SHORT
83A P1014083A ROCKER ARM
84A P1014084A ECCENTRIC
85A P1014085A LEVER, LONG
86A P1014086A KNOB, 3 ⁄
8
-16
87A P1014087A SPACER
88A PB21 HEX BOLT 3 ⁄
8
"-16 x 3 ⁄
4
"
89 PSB31 CAP SCREW 10-24 x 5 ⁄
8
"
90 P1014090 MOTOR CORD
91 PB16 HEX BOLT 3 ⁄
8
"-16 x 1 1 ⁄
2
"
92 PW02 FLAT WASHER 3 ⁄
8
"
93 P1014093 WASHER PLATE
94 P1014094 KNOB
95 PLW01 LOCK WASHER 5 ⁄
16
"
96 PSS18 SETSCREW 5 ⁄
16
"-18 x 3 ⁄
4
"
97 P1014097 FENDER WASHER
98 PN11 HEX NUT 3 ⁄
8
''-24
99 P1014099 GRAPHITE PAD
100 P1014100 DUST PORT
101 P1014101 FENDER WASHER 3 ⁄
8
"
102 P1014102 DIRECTION SCALE
103 P1014103 POINTER
104 P1014104 NAME PLATE
105 PN08 HEX NUT 3 ⁄
8
"-16
106 PN07 HEX NUT 10-24
107 PB19 HEX BOLT 1 ⁄
4
''-20 x 1 ⁄
2
''
108 PW06 FLAT WASHER 1 ⁄
4
''
109 P1014109 LEG
110 P1014110 LOWER BRACE, LONG
111 P1014111 LOWER BRACE, SHORT
112 P1014112 UPPER BRACE, LONG
113 P1014113 UPPER BRACE, SHORT
114 P1014114 IDLER ROLLER GUARD
01 P1014001 DUST COVER
02 PR03M SNAP RING 12MM
03 P6201 BEARING 6201-2RS
04 P1014004 DRIVE SHAFT
05 G1214 SANDING BELT 6'' X 48''
06 PK02M KEY 5 X 5X 40
07 PR02M SNAP RING 14MM
08 P1014008 SANDING BELT FRAME
09 P1014009 BACK STOP
10 PSS02 SETSCREW 5 ⁄
16
"-18 x 3 ⁄
8
"
11 P1014011 DRIVE ROLLER
12 PN02 HEX NUT 5 ⁄
16
"-18
13 PW07 FLAT WASHER 5 ⁄
16
"
14 P1014014 KNOB
15 P1014015 BEARING 6202-2RSNR
18 PCB06 CARRIAGE BOLT 5 ⁄
16
"-18x1 1 ⁄
4
"
19 P1014019 PULLEY COVER
20 P1014020 TABLE LOCK HANDLE
21 P1014021 CAST IRON DISC 9''
22 G1217 SANDING DISC
23 P1014023 TABLE
24 P1014024 TRUNNION
25 PW06 FLAT WASHER 1 ⁄
4
"
26 PS04 PHILLIPS SCREW 1 ⁄
4
"-20 x 1 ⁄
2
"
27 PS01 PHILLIPS SCREW 10-24 x 1 ⁄
2
"
28 P1014028 POINTER
29 P1014029 TABLE SUPPORT BRACKET
30 P1014030 SUPPORT BAR
31 P1014031 PIN
32 PB09 HEX BOLT 5 ⁄
16
"-18 x 1 ⁄
2
"
33 P1014033 TABLE MOUNT
34 PVFM25 V-BELT FM25
35 P1014035 PULLEY
36 P1014036 MOTOR PULLEY
37 P1014037 KNOB
39 PB12 HEX BOLT 5 ⁄
16
"-18 x 1 1 ⁄
4
"
40 P1014040 BRACKET
41 PB03 HEX BOLT 5 ⁄
16
"-18 x 1''
42 PSS03 SETSCREW 1 ⁄
4
"-20 x 3 ⁄
8
"
43 P1014043 MOTOR
44 P1014044 KNOB
49 P1014049 STRAIN RELIEF
50 P1014050 SWITCH PLATE
52 P1014052 BASE
53A PSW07 SWITCH
56 PN04 HEX NUT 5 ⁄
8
''-11
