Identification – Grizzly G0639 User Manual
Page 7

Model G0639 22-Ton Hydraulic Log Splitter
-5-
A. 2" Tow Ball Receiver
B. 4" Hydraulic Cylinder Assembly
C. Transfer Hose
D. Control Lever and Valve
E. High Pressure Hydraulic Line
F. Splitter Wedge
G. Low Pressure Hydraulic Return Line
H. Log Cradle
I. Splitter Foot
Identification
Figure 1. G0639 identification front view.
A
B
C
O
N
M
L
K
J
I
H
G
F
D
E
Q
P
J. Splitter Beam
K. Rear Landing Leg
L. Hydraulic Tank
M. Tubeless Tire
N. Low Pressure Hydraulic Suction Line
O. Briggs & Stratton Gasoline Engine
P. Front Landing Leg
Q. Breakaway Safety Chain
