20
HARNESS SYSTEM
- removal and re-assembly
Harness Removal:
• Remove harness strap loops from Splitter
Plate on back of car seat.
• Pull harness strap out of car seat, harness
clip and tongues.
Store all parts for future use.
• Remove crotch strap (see page 19).
When re-assembling harness system, be sure
harness straps are not twisted.
Harness Re-assembly:
Thread end of harness strap down through
slot in seat pad, under both clips on bottom
and back up through slot in opposite side of
car seat pad, through harness tongues and
harness clip.
IMPORTANT: Harness strap MUST be threaded
over adjustment strap on bottom of car seat as
shown in illustrations.
Thread ends of harness straps through
matching shoulder slots in back of seat pad
and car seat.
Re-attach harness straps to Splitter Plate on
bottom
Put right strap loop on Splitter Plate first, then
attach left strap loop.
Re-attach crotch strap (see page 19).
1
2
3
