Performance certified is for installation type B: Free inlet, Ducted outlet. Power rating (Bhp) does not include transmission losses. Performance ratings do not
include the effects of appurtenances (accessories).
The sound power level ratings shown are in decibels, referred to 10
-12 watts, calculated per AMCA Standard 301. Values shown are for inlet L
Wi
, L
Wi
A and outlet L
Wo
,
L
Wo
A sound power levels for installation type B: Free inlet, Ducted outlet. Ratings for inlet sound do not include the effects of duct end correction. Ratings for outlet
sound include the effects of duct end correction. The A-weighted sound power ratings shown have been calculated per AMCA Standard 301. The AMCA Certified
Ratings Seal applies to L
Wi
A and L
Wo
A values only.
Performance Data
Shaded values show where Class I fan selections are more efficient than Class II.
QEI-12 Class II
Performance Data
Maximum Fan RPM 4000
Specification Data
Maximum Motor
Frame Size
184T
Minimum Motor
Starting hp
1/3 hp .25 kW
Wheel Diameter 15 in. 381 mm
Approximate Weight
(Less Motor & Drives)
180 lbs. 82 kg.
Maximum Bhp = (Fan RPM / 2345) 3
Outlet Velocity (FPM) = CFM / 1.56
Tip Speed (FPM) = Fan RPM x 3.93
% WOV = (CFM x 100) / (Fan RPM x 1.16)
Imperial data —
Metric data
CFM OV
STATIC PRESSURE (inches wg)
0 0.5 1 2 3 4 5 6 7
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1400 891 1203 0.08 1460 0.21 1696 0.37 2131 0.75 2510 1.21
1600 1019 1375 0.12 1604 0.26 1812 0.43 2213 0.84 2574 1.31 2894 1.84
1800 1146 1547 0.17 1752 0.33 1943 0.51 2301 0.93 2641 1.43 2957 1.98 3239 2.59
2000 1273 1719 0.24 1906 0.41 2080 0.60 2410 1.05 2728 1.56 3021 2.13 3302 2.76 3557 3.43
2200 1401 1891 0.32 2062 0.50 2223 0.71 2522 1.17 2817 1.71 3102 2.30 3366 2.95 3620 3.64 3854 4.37
2400 1528 2062 0.41 2221 0.61 2370 0.83 2653 1.32 2924 1.88 3190 2.49 3443 3.15 3684 3.86 3917 4.62
2600 1656 2234 0.52 2381 0.74 2519 0.97 2785 1.48 3035 2.06 3283 2.70 3530 3.38 3759 4.11 3981 4.88
2800 1783 2406 0.65 2543 0.88 2673 1.13 2921 1.66 3157 2.27 3393 2.92 3618 3.63 3846 4.38
3000 1910 2578 0.80 2706 1.05 2829 1.31 3064 1.87 3289 2.49 3504 3.17 3722 3.90 3934 4.67
3200 2038 2750 0.98 2871 1.24 2987 1.51 3209 2.10 3421 2.74 3624 3.44 3831 4.19
3400 2165 2922 1.17 3036 1.45 3145 1.74 3356 2.35 3556 3.01 3755 3.74 3943 4.50
3600 2292 3094 1.39 3202 1.68 3305 1.99 3504 2.62 3699 3.32 3887 4.06
Inlet Sound Power, L
Wi
[dB ref 10 -12 watts] Outlet Sound Power, L
Wo
[dB ref 10 -12 watts]
RPM % WOV 1 2 3 4 5 6 7 8 L
Wi
A RPM % WOV 1 2 3 4 5 6 7 8 L
Wo
A
1600
100 72 77 77 74 70 69 69 56 77
1600
100 87 83 78 75 74 71 69 58 79
80 74 79 75 69 66 67 61 55 73 80 84 85 73 70 71 69 63 58 76
60 73 80 75 66 64 64 58 55 72 60 85 84 73 68 68 66 61 58 75
50 74 80 76 65 63 63 57 54 72 50 87 84 73 68 68 65 60 59 74
2200
100 76 77 78 78 76 75 76 67 82
2200
100 89 85 80 80 80 77 75 67 84
80 76 78 76 74 72 72 68 63 78 80 87 84 77 76 77 74 70 66 81
60 76 79 75 71 70 70 66 62 76 60 88 82 77 74 74 72 67 66 79
50 77 79 75 71 69 68 64 62 76 50 89 83 77 74 74 71 67 66 79
2800
100 83 82 83 80 80 78 78 79 86
2800
100 97 89 86 83 84 81 78 78 89
80 86 86 81 77 76 75 73 68 82 80 91 90 83 80 82 79 75 71 86
60 85 91 79 76 75 75 72 67 82 60 91 87 83 79 80 77 73 71 85
50 86 89 80 76 74 74 70 67 81 50 93 88 83 79 79 76 73 70 84
3400
100 83 86 85 83 83 82 80 85 90
3400
100 98 91 88 86 88 85 81 84 92
80 87 86 83 80 80 79 76 72 85 80 93 90 86 83 85 82 79 75 89
60 87 90 82 79 79 78 76 71 85 60 93 89 86 83 84 81 78 75 89
50 87 89 83 80 78 78 75 71 85 50 95 89 86 83 83 81 77 74 88
4000
100 80 89 86 86 87 86 84 89 93
4000
100 95 90 90 89 91 89 85 87 96
80 82 83 83 81 83 82 79 76 88 80 94 88 87 85 88 86 82 78 92
60 84 82 85 81 82 81 79 75 87 60 94 89 89 85 88 85 82 78 92
50 84 83 85 83 82 81 79 75 88 50 94 89 88 86 87 84 82 78 91
7½
5
3
2
1½
1
¾
½
3400
4000
2800
2200
1600
Static Pr
essur
e (in. wg)
Static Pr
essur
e (Pa x 100)
Volume (cfm x 1000)
0 1 2 3 4 5
0 2 4 6 8
3 Volume (m /hr x 1000)
25
20
15
10
5
0
12
10
8
6
4
2
0
60% WOV
50% WOV
70% WOV
80% WOV
90% WOV
RPM
BHP
% WOV
Density 0.075 lb/ft
3
Density 1.2 kg/m 3
DO
NO
T S
EL
EC
T
TO
T
H
E
LE
FT
O
F
TH
IS
S
YS
TE
M
C
U
R
VE
