Page 17
17
870 RPM
(60 Hz)
Model QEID
36—54
Volume (cfm x 1000)
Static
Pressure
(in. wg)
10
20
30
40
50
100
8
6
4
2
0
44
40
36
49
54
QEID Dimensional Data
Size
Slip Fit O.D.
Length*
Weight**
inches
mm
inches
mm
lbs.
kg.
12
17.13
435
25.0
635
100
45
15
20.88
530
25.0
635
140
65
16
23.00
584
26.0
660
170
80
18
25.38
645
29.0
737
200
95
20
27.81
706
34.0
864
250
115
22
30.88
784
35.5
902
370
170
24
34.00
864
41.5
1054
480
220
27
37.44
951
45.0
1143
570
260
30
41.63
1057
Refer to
table below.
860
390
33
45.75
1162
1140
520
36
50.56
1284
1360
620
40
55.75
1416
1650
750
44
61.63
1565
2190
995
49
67.75
1721
2700
1225
54
75.00
1905
3130
1420
* Length varies with motor frame size.
Refer to Length table shown.
** Weight is for unit only and does not
include motor.
Length
Slip Fit
O.D.
Length — inches (millimeters)
Size
254/6 T
284/6 T
324/6 T
364/5 T
404/5 T
444/5 T
30
45.5 (1156)
50.0 (1156)
50.0 (1156)
33
46.5 (1181)
54.0 (1372)
54.0 (1372)
54.0 (1372)
36
50.5 (1283)
58.0 (1473)
58.0 (1372)
58.0 (1372)
40
56.5 (1435)
61.0 (1549)
61.0 (1549)
44
64.0 (1626)
64.0 (1626)
70.0 (1778)
49
74.5 (1892)
74.5 (1892)
80.5 (2045)
54
77.0 (1956)
77.0 (1956)
83.0 (2108)
