-D- G8220 Wet/Dry Bench Grinder
01 P8220001 SIDE GUARD
02 P8220002 COMBO HD LKG 10-24 X 5 ⁄
8
"
03 PN15 HEX NUT 9 /
16
"-12
04 P8220004 WHEEL FLANGE
05 P8220005 GRINDING WHEEL 80 GRIT
06 P8220006 COMBO HD LKG 10-24 X 1 ⁄
2
"
08 P8220008 WHEEL GUARD
10 P8220010 TOOL REST
12 P8220012 WING NUT
13 P8220013 BRACKET - TOOL REST
14 PW03M FLAT WASHER M6
15 PLW02 LOCK WASHER 1 ⁄
4
"
16 PB02M HEX BOLT M6-1 X 12
17 P8220017 BRACKET - EYE SHIELD
18 PB15 HEX BOLT 5/16-18 X 3 /
8
"
19 PN04M HEX NUT M4-0.7
20 PW05M FLAT WASHER 4MM
21 PS02M PHLP HD SCR M4-.7 X 12
22 P8220022 EYE SHIELD
23 P8220023 BUSHING
24 P6202 BALL BEARING 6202
25 P8220025 MOTOR STATOR
26 P8022026 MOTOR ROTOR
27 PSC1614 SPADE CONNECTOR
28 P8220028 CAPACITOR 8 MFD
29 P8220029 PLATE
30 P8220030 REAR BODY
31 P8220031 STRAIN RELIEF
32 PWRCRD110L POWER CORD 110V, LONG W/PLUG
33 P8220033 FRONT BODY
34 PB03 HEX BOLT 5/16-18 X 1
35 PW07 FLAT WASHER 5 ⁄
16
"
36 PS22 PHLP HD SCR 10-24 X 5 ⁄
8
"
37 P8220037 POWER SWITCH
38 P8220038 BASE
39 P8220039 BASE FOOT
40 PS01 PHLP HD SCR 10-24 X 1 /
2
"
41 PRP22M ROLL PIN 4 X 32
42 PFH01 FLAT HD SCR 10-24 X 3/8
43 P8220043 WORM
44 P8220044 RING PLATE
45 P6200 BALL BEARING 6200
46 P8220046 GEAR BOX
47 PS24M PHLP HD SCR M6-1 X 10
48 PRP22M ROLL PIN 4 X 32
49 P8220049 WORM GEAR
50 P8220050 GEAR BOX COVER
51 P8220051 SPINDLE
52 P8220052 DRAIN HOSE
53 P8220053 WATER TRAY
54 P8220054 SPONGE
55 P8220055 WATER RESERVOIR
56 P8220056 WATER VALVE
57 P8220057 WHEEL MOUNT WASHER
58 P8220058 PLATE MTD WHEEL 1000
59 P8220059 WHEEL MOUNT NUT
60 P8220060 WRENCH
61 P8220061 LOCKING KNOB
62 P8220062 SUPPORT BRACKET
63 PB41M HEX BOLT M4-.7 X 30
64 P8220064 KNOB
65 P8220065 TOOL HOLDER
66 P8220066 TOOL REST WET WHEEL
67 P8220067 GUIDE
68 PR05M EXT RET RING 15MM
69 PW07 FLAT WASHER 5 ⁄
16
"
70 PS25M PHLP HD SCR M4-.7 X 30
REF PART # DESCRIPTION REF PART # DESCRIPTION
