GXV-3000 User Manual
Grandstream Networks, Inc.
- 6 -
Power 12V DC power port
RCA Output RCA Output Interface to external display like TV set
Headset 2.5mm Headset port
2.3 Wall Mount
GXV-3000 can be wall mounted. The two wall mount sustaining brackets can be attached to the bot-
tom of the main body:
User can simply place the device against the wall with two holes to the fixed hanger and the two sus-
taining brackets balance the bottom to position the phone on the wall.
User will need to pull out the tab (extension downward) from handset cradle on the top of the handset
rest, and rotate the tab and plug it back into the slot with the extension up for handset holding.
Tab
Handset
Rest
Tab with exten-
sion down
Tab with exten-
sion up
