HandTone-496 User Manual

Grandstream Networks, Inc.

WAN side http

access:

Yes (WAN side access to http server will be rejected if set to

No)

Update

Admin Password

This contains the password to access the Advanced Web Configuration page.
This field is case sensitive.

SIP Server

SIP Server’s URI or IP address

Outbound Proxy

SIP Outbound Proxy Server’s URI or IP address

SIP User ID

SIP service subscriber’s User ID

Authenticate ID

SIP service subscriber’s Authenticate ID. Can be identical to or different from
SIP User ID

Authenticate
Password

SIP service subscriber’s account password

Name

SIP service subscriber’s name which will be used for Caller ID display

Register Expiration This parameter allows the user to specify the time frequency (in minutes) the

HandyTone ATA refreshes its registration with the specified registrar. The
default interval is 60 minutes (or 1 hour). The maximum interval is 65535
minutes (about 45 days).

Local SIP port

This parameter defines the local SIP port the HandyTone ATA will listen and
transmit. The default value for FXS port 1 is 5060. The default value for FXS
port 2 is 5062.

Local RTP port

This parameter defines the local RTP-RTCP port pair the HandyTone ATA will
listen and transmit. It is the base RTP port for channel 0. When configured,
channel 0 will use this port _value for RTP and the port_value+1 for its RTCP;
channel 1 will use port_value+2 for RTP and port_value+3 for its RTCP. The
default value for FXS port 1 is 5004. The default value for FXS port 2 is 5008.

Enable Call
Features

Default is No. If set to Yes, Call Forwarding & Do-Not-Disturb are supported
locally

Send DTMF

This parameter controls how DTMF events are transmitted. There are 3 ways:
in audio which means DTMF is combined in audio signal (not very reliable
with low-bit-rate codec), via RTP (RFC2833), or via SIP INFO.

DTMF Payload
Type

This parameter sets the payload type for DTMF using RFC2833
