Grizzly H6332 - Manual (Page 17)

H6332 1 1 ⁄
4
" Brad Nailer -15 -
H6332 PARTS LIST
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH6332001 STEEL BALL 44 PH6332044 FIXED COVER
2 PH6332002 ORIENTATION SPRING 45 PSB15M CAP SCREW M5-.8 X 20
3 PH6332003 SHOULDER BOLT M4-.7 X 16 46 PH6332046 TORSION SPRING
4 PH6332004 DIRECTION SPRING 47 PRP18M ROLL PIN 4 X 12
5 PH6332005 AIR DEFLECTOR 48 PH6332048 NOSE COVER LOCKING PIN
6 PSB15M CAP SCREW M5-.8 X 20 49 PH6332049 COMPRESSION SPRING
7 PLW01M LOCK WASHER 5MM 50 PH6332050 SLIDE BLOCK
8 PH6332008 CYLINDER CAP 51 PH6332051 HANDLE COVER
9 PH6332009 SEALING WASHER 18MM 52 PH6332052 HANDLE
10 PH6332010 O-RING 17 X 2.65 53 PSB110M CAP SCREW M4-.7 X 6
11 PH6332011 COMPRESSION SPRING 54 PH6332054 NOSE COVER
12 PH6332012 O-RING 33.6 X 2 55 PRP61M ROLL PIN 3 X 12
13 PH6332013 SWITCH PISTON 56 PH6332056 MOVABLE NOSE COVER
14 PH6332014 GASKET 57 PH6332057 DRIVER GUIDE
15 PH6332015 O-RING 30 X 3 58 PSB16M CAP SCREW M4-.7 X 16
16 PH6332016 O-RING 23.5 X 2 59 PH6332059 SAFETY GUARD CLAMP B
17 PH6332017 MAIN PISTON 60 PSB145M CAP SCREW M3-.5 X 16
18 PH6332018 O-RING 48.7 X 2.65 61 PH6332061 INLAY STRIP
19 PH6332019 COLLAR 62 PH6332062 MOVABLE MAGAZINE
20 PH6332020 CYLINDER 63 PSS23M SET SCREW M4-.7 X 10
21 PH6332021 BUMPER 64 PH6332064 MAGAZINE SLIDE PLATE
22 PH6332022 PISTON SLOT WASHER 65 PH6332065 SPRING CAP
23 PH6332023 GUN BODY 66 PH6332066 COMPRESSION SPRING
24 PH6332024 DIRECTION SEAT 67 PSB56M CAP SCREW M3-.5 X 10
25 PRP55M ROLL PIN 3 X 27 68 PH6332068 FIX SEAT
26 PH6332026 COMPRESSION SPRING 69 PH6332069 TORSION SPRING
27 PH6332027 ADJUSTMENT SEAT 70 PRP42M ROLL PIN 3 X 20
28 PH6332028 ROLL PIN 1.5 X 8 71 PH6332071 CATCH LEVER
29 PH6332029 ADJUSTMENT BOLT 72 PSB18M CAP SCREW M4-.7 X 8
30 PH6332030 COMPRESSION SPRING 73 PH6332073 MAG. CONNECTOR PLATE
31 PH6332031 SAFETY GUARD 74 PH6332074 MAGAZINE HOUSING
32 PH6332032 O-RING 7 X 1.5 75 PH6332075 SAFETY GUARD CLAMP A
33 PH6332033 TRIGGER VALVE GUIDE 76 PSB23M CAP SCREW M4-.7 X 12
34 PH6332034 COMPRESSION SPRING 77 PH6332077 RUBBER HANDGRIP
35 PH6332035 O-RING 1.9 X 1.1 78 PLN08M LOCK NUT M3-.5
36 PH6332036 SWITCH PIPE 79 PH6332079 O-RING 40 X 2.65
37 PH6332037 O-RING 11.2 X 1.6 80 PH6332080 END CAP
38 PH6332038 SWITCH SEAT 81 PH6332081 AIR PLUG 1/4 NPT
39 PH6332039 O-RING 13.2 X 1.9 82 PH6332082 PISTON REPAIR KIT
40 PH6332040 COMPRESSION SPRING 83 PH6332083 CARRYING CASE
41 PH6332041 TRIGGER 84 PAW03M HEX WRENCH 3MM
42 PH6332042 SAFETY PLATE 85 PAW04M HEX WRENCH 4MM
43 PRP64M ROLL PIN 3 X 18
