Goodman Mfg GKS90904CXAD - Manual (Page 9)

Chassis
Ref.
No: Part
No:
Description:
Ref.
No: Part
No:
Description:
Image 1:
BASE PAN (M1, M2, M3, M4, M5, M6, M7, M8) 0121F00050DGS 11
BASE PAN (M9, M10, M11, M12, M13, M14, M15,
M16) 0121F00051DG 11
BASE PAN (M17, M18, M19, M20, M21, M22, M23) 0121F00052DG 11
BLOWER DECK (M1, M2, M3, M4, M5, M6, M7, M8) 0121F00043 31
BLOWER DECK (M9, M10, M11, M12, M13, M14,
M15, M16) 0121F00045 31
BLOWER DECK (M17, M18, M19, M20, M21, M22,
M23) 0121F00048 31
COIL GASKET (M1, M2, M3, M4, M5, M6, M7, M8) 0154F00000P 41
COIL GASKET (M9, M10, M11, M12, M13, M14,
M15, M16) 0154F00001P 41
COIL GASKET (M17, M18, M19, M20, M21, M22,
M23) 0154F00002P 41
BACK PANEL (M1, M2, M3, M4, M5, M6, M7, M8) 20273208 81
BACK PANEL (M9, M10, M11, M12, M13, M14, M15,
M16) 20273210 81
BACK PANEL (M17, M18, M19, M20, M21, M22,
M23) 20273212 81
DECK RAIL (M1, M2, M3, M4, M5, M6, M7, M8) 0121F00018P 101
DECK RAIL (M9, M10, M11, M12, M13, M14, M15,
M16) 0121F00019P 101
DECK RAIL (M17, M18, M19, M20, M21, M22, M23) 20191303 101
TOP COVER ASSY (M9, M10, M11, M12, M13,
M14, M15, M16) 0270F00001PS 111
TOP COVER ASSY (M17, M18, M19, M20, M21,
M22, M23) 0270F00002PS 111
TOP COVER ASSY (M1, M2, M3, M4, M5, M6, M7,
M8) 0270F00100PS 111
SIDE RAIL (M1, M2, M3, M4, M5, M6, M7, M8) 20191602 121
SIDE RAIL (M9, M10, M11, M12, M13, M14, M15,
M16) 20191603 121
SIDE RAIL (M17, M18, M19, M20, M21, M22, M23) 20191604 121
SIDE PANEL LH 0121F00092DGS 141
SIDE PANEL RH 0121F00090DGS 151
INTERLOCK SWITCH B1370818 221
FLUE PIPE 22309501 231
ELBOW 20171802 241
ID BLOWER 22307501S 271
FA COUPLING 20049701 281
HIGH VOLTAGE BOX (M1, M2, M4, M5, M9, M10,
M12, M13, M17, M18, M20, M21) 10736102 311
COVER, HIGH VOLTAGE BOX (M1, M2, M4, M5,
M9, M10, M12, M13, M17, M18, M20, M21) 10736201 331
PLASTIC SEALER (M20, M21, M22, M23) M0275521 391
JUNCTION BOX-PLA (M3, M6, M7, M8, M11, M14,
M15, M16, M19, M22, M23) 0161F00004 411
SNAP BUSHING (M1, M2, M4, M5, M9, M10, M12,
M13, M17, M18, M20, M21) A4554801 421
JUNCTION BOX-LID (M3, M6, M7, M8, M11, M14,
M15, M16, M19, M22, M23) 0161F00005 431
ID BLOWER SHIELD 11165107 591
Image 1:
HOSE CLAMP (QTY 2) 0163M00049 611
UNIVERSAL BUSHING UB 875 (QTY 2) B1392104 741
GASKET (QTY 2) 20194608 791
GASKET (M1, M2, M3, M4, M5, M6, M7, M8) 20194605 811
GASKET (M9, M10, M11, M12, M13, M14, M15,
M16) 20194606 811
GASKET (M17, M18, M19, M20, M21, M22, M23) 20194607 811
HEAT EXCHANGER INSULATION (M17, M18, M19,
M20, M21, M22, M23) C6415909 NS
HEAT EXCHANGER INSULATION (M1, M2, M3,
M4, M5, M6, M7, M8) C6415910 NS
HEAT EXCHANGER INSULATION (M9, M10, M11,
M12, M13, M14, M15, M16) C6415911 NS
PRESSURE SWITCH HOSE 0164M00002 NS
Image 2:
AUXILIARY LIMIT BRACKET 10861101 352
AUXILIARY LIMIT (M20, M21, M22, M23) 10123519 362
MANUAL RESET LIMIT (M1, M2, M3, M4, M5, M6,
M7, M8, M9, M10, M11, M12, M13, M14, M15, M16,
M17, M18, M19) 10123535 362
Expanded Model Nomenclature
M1 - GKS90453BXAA
M2 - GKS90453BXAB
M3 - GKS90453BXAC
M4 - GKS90703BXAA
M5 - GKS90703BXAB
M6 - GKS90703BXAC
M7 - GKS90703BXAD
M8 - GKS90703BXAE
M9 - GKS90704CXAA
M10 - GKS90704CXAB
M11 - GKS90704CXAC
M12 - GKS90904CXAA
M13 - GKS90904CXAB
M14 - GKS90904CXAC
M15 - GKS90904CXAD
M16 - GKS90904CXAE
M17 - GKS90905DXAA
M18 - GKS90905DXAB
M19 - GKS90905DXAC
M20 - GKS91155DXAA
M21 - GKS91155DXAB
M22 - GKS91155DXAC
M23 - GKS91155DXAD
9 RP-410F www.goodmanmfg.com
