Goodman Mfg GKS90904CXAD - Manual (Page 11)

Heat Exchanger/Manifold/Gas Valve
Ref.
No: Part
No:
Description:
Ref.
No: Part
No:
Description:
Image 1:
IGNITOR 20165703S 11
GAS VALVE (36G) B1282628 21
ORIFICE (QTY 2) 10716003 31
FLAME SENSOR 0130F00010 41
MANUAL RESET LIMIT 10123533 51
MANIFOLD - 2 BRNR (M1, M2, M3) 20196401 61
MANIFOLD - 3 BRNR (M4, M5, M6, M7, M8, M9,
M10, M11) 20196402 61
MANIFOLD - 4 BRNR (M12, M13, M14, M15, M16,
M17, M18, M19) 20196403 61
MANIFOLD - 5 BRNR (M20, M21, M22, M23) 20196404 61
BECKETT BURNER (QTY 2) 10735102S 71
HEAT EXCHANGER ASSY 2B (M1) 0257F00038P 81
HEAT EXCHANGER ASSY 2B (M3) 0257F00148 81
HEAT EXCHANGER ASSY 3B (M9) 0257F00040P 81
HEAT EXCHANGER ASSY 3B (M11) 0257F00150 81
HEAT EXCHANGER ASSY 3B (M4, M6, M7) 0257F00172S 81
HEAT EXCHANGER ASSY 3B (M8) 0257F00181 81
HEAT EXCHANGER ASSY 4B (M19) 0257F00152 81
HEAT EXCHANGER ASSY 4B (M12, M14, M15,
M16) 0257F00173S 81
HEAT EXCHANGER ASSY 4B (M17) 20418617 81
HEAT EXCHANGER ASSY 5B (M2, M5, M10, M13,
M18, M20, M21, M22, M23) 0257F00174S 81
BURNER BRACKET 2B (M1, M2, M3) 20190410 91
BURNER BRACKET 3B (M4, M5, M6, M7, M8, M9,
M10, M11) 20190411 91
BURNER BRACKET 4B (M12, M13, M14, M15, M16,
M17, M18, M19) 20190412 91
BURNER BRACKET 5B (M20, M21, M22, M23) 20190413 91
FRONT COVER (M1) 20170801AS 131
FRONT COVER (M4, M8) 20170802AS 131
FRONT COVER (M2, M3) 20170807AS 131
FRONT COVER (M5, M6, M7) 20170808AS 131
FRONT COVER (M9, M10, M11) 20170901AS 131
FRONT COVER (M12) 20170902AS 131
FRONT COVER (M13, M14, M15, M16) 20170904AS 131
FRONT COVER (M17, M18, M19) 20171001AS 131
FRONT COVER (M20, M21, M22, M23) 20171002AS 131
COIL GASKET (M1, M2, M3, M4, M5, M6, M7, M8) 0154F00000P 141
COIL GASKET (M9, M10, M11, M12, M13, M14,
M15, M16) 0154F00001P 141
COIL GASKET (M17, M18, M19, M20, M21, M22,
M23) 0154F00002P 141
TUBE PLUG (QTY AR) M0326804 161
ORIFICE SHIELD (M1, M2, M3) 11072201 321
ORIFICE SHIELD (M4, M5, M6, M7, M8, M9, M10,
M11) 11072202 321
Image 1:
ORIFICE SHIELD (M12, M13, M14, M15, M16, M17,
M18, M19) 11072203 321
ORIFICE SHIELD (M20, M21, M22, M23) 11072204 321
PRIMARY LIMIT-BLUE (M4, M5, M6, M7, M8, M9,
M10, M11, M17, M18, M19) 20162903 371
PRIMARY LIMIT-TEMPERATURE CONTROL (M1,
M2, M3, M12, M13, M14, M15, M16) 20162904 371
PRIMARY LIMIT-WHITE (M20, M21, M22, M23) 20162906 371
PRESSURE SWITCH-LIGHT BLUE (M1, M9, M17) 20197312 381
PRESSURE SWITCH-OLIVE (M16) 0130F00002P 381
PRESSURE SWITCH-ORANGE (M12, M20) 20197310 381
PRESSURE SWITCH-RED (M4, M18, M19) 0130F00004 381
PRESSURE SWITCH-SUNGOLD (M2, M3, M5, M6,
M7, M8, M10, M11, M13, M14, M15, M21, M22, M23) 0130F00001P 381
Expanded Model Nomenclature
M1 - GKS90453BXAA
M2 - GKS90453BXAB
M3 - GKS90453BXAC
M4 - GKS90703BXAA
M5 - GKS90703BXAB
M6 - GKS90703BXAC
M7 - GKS90703BXAD
M8 - GKS90703BXAE
M9 - GKS90704CXAA
M10 - GKS90704CXAB
M11 - GKS90704CXAC
M12 - GKS90904CXAA
M13 - GKS90904CXAB
M14 - GKS90904CXAC
M15 - GKS90904CXAD
M16 - GKS90904CXAE
M17 - GKS90905DXAA
M18 - GKS90905DXAB
M19 - GKS90905DXAC
M20 - GKS91155DXAA
M21 - GKS91155DXAB
M22 - GKS91155DXAC
M23 - GKS91155DXAD
11 RP-410F www.goodmanmfg.com
