Model h7826 (Mfg. since 2/07) -9 -
section 3: operations
oiling nailer
figure 8. lubricating nailer via air inlet.
another option to manual oiling would be
to install a lubricator, or a filter/lubricator/
regulator unit, in your air compressor line.
if your air compressor line already has a
lubricator, then regular lubrication of your
nailer will not be necessary. Just make
sure there is always pneumatic tool oil in
the lubricator.
loading nailer
When replacing nails in your model
h7826, follow these guidelines:
nails: l-shaped cleat nails
length: 1"–2"
Capacity: 100
note: Use 1 1 ⁄
2
" nails to install 1 ⁄
2
" flooring.
Use 2" nails to install 3 ⁄
4
" flooring.
to load your nailer:
1. disConnECt nailEr FroM thE
air supply!
2. slide a strip of nails, pointed-end
down, into the magazine as shown in
figure 9.
3. push the button inside the pusher (inset
photo in figure 9), pull the pusher all
the way back, then allow the pusher to
slide forward against the nail strip.
figure 9. loading nails into nailer.
place two to six drops of pneumatic tool
oil in the nailer air inlet (as shown in
figure 8) every 2 hours of continuous
use. Wipe off any excess oil near the nailer
exhaust to avoid dust build-up. Model
g2820 pneumatic tool oil is available
from grizzly.
