Page 3
")+"
<%+)-LZaY^c\;jbZ:migVXidg
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
100
P0648100
MOTOR BASE
128
P0648128
REDUCER
101
PB07
HEX BOLT 5/16-18 X 3/4
129
PFN07M
FLANGE NUT M4-.7
102
PW07
FLAT WASHER 5/16
130
PW07
FLAT WASHER 5/16
103
PW02
FLAT WASHER 3/8
131
PB07
HEX BOLT 5/16-18 X 3/4
104
PN08
HEX NUT 3/8-16
132
P0648132
RECOVERY AXLE
105
P0648105
MOTOR 2HP 220V 3PH
133
PHTEK8
TAP SCREW #8 X 1/2
105-1 P0648105-1 FAN COVER
134
P0648134
PIPE
105-2 P0648105-2 MOTOR FAN
135
P0648135
SENSOR EYE
106
PN08
HEX NUT 3/8-16
136
PS01
PHLP HD SCR #10 X 1/2
107
PW02
FLAT WASHER 3/8
137
P0648137
RECOVERY BOX
108
PN08
HEX NUT 3/8-16
138
PHTEK8
TAP SCREW #8 X 1/2
109
P0648109
LOWER FRONT DOOR
139
P0648139
CONVEYOR SWITCH
110
P0648110
HANDLE ROTATION PLATE
140
P0648140
ELECTRICAL BOX DOOR
111
P0648111
WATERPROOF SWITCH
141
P0648141
HINGE
112
P0648112
SWITCH HANDLE
142
PHTEK23
TAP SCREW #10 X 1/2
113
P0648113
UPPER FRONT DOOR
143
P0648143
RIGHT DOOR
114
P0648114
SPECIAL HEX BOLT M5-.8 X 10
144
P0648144
GLASS WINDOW 621.2 X 406.8MM
115
P0648115
HINGE
145
P0648145
GLASS SEAL 2060MM
116
P0648116
COVER
146
P0648146
SPECIAL SCREW M5-.8 X 10
117
PS17
PHLP HD SCR #8-32 X 1/2
147
P0648147
HINGE
118
P0648118
CHAIN HOUSING C
148
P0648148
CONTROL PANEL
119
PS01
PHLP HD SCR #10-24 X 1/2
149
P0648149
CONTROL PANEL LOCK
120
P0648120
CHAIN
150
P0648150
HINGE
121
PN17
HEX NUT 3/4-10
151
P0648151
SPECIAL HEX BOLT M5-.8 X 10
122
P0648122
GEAR 21T
152
P0648152
COVER BOARD
123
P0648123
GEARED BEARING BASE
153
PHTEK23
TAP SCREW #8 X 1/2
124
PS64M
PHLP HD SCR M4-.7 X 65
157
P0648157
DIGITAL CONTROL PANEL
125
PW07
FLAT WASHER 5/16
158
P0648158
EMERGENCY STOP SWITCH
126
PB07
HEX BOLT 5/16-18 X 3/4
159
P0648159
BUZZER
127
P0648127
BASE
163
P0648163
WARNING LAMP
Parts List
