SPDIF Output Device (Optional Device)
3. Connect co-ax ial or optical output to the SPDIF
decoder.
1. Connect the SPDIF output dev ice to the rear
bracket of PC, and fix it w ith screw .
2. Connect SPDIF w ire to the motherboard.
A “SP DIF output” dev ice is available on the
motherboard. Cable with rear bracket is provided
and could link to the “SP DIF output” connector
(A s picture.) For the further linkage to decoder,
rear bracket provides coax ial cable and Fiber
connecting port.
