Hardware Installation - 15 -
English
Dual Channel Memory Configuration
The GA-945PLM-DS2/GA-945PLM-S2 supports the Dual Channel Technology.
After operating the Dual Channel Technology, the bandwidth of memory bus
will double.
The GA-945PLM-DS2/GA-945PLM-S2 includes 2 DIMM sockets.
If you want to operate the Dual Channel Technology, please note the following explanations:
1. Dual Channel mode will not be enabled if only one DDRII memory module is installed.
2. To enable Dual Channel mode, please insert two DDRII memory modules (it is recom-
mended to use memory modules of identical brand, size, chips, and speed) into DDRII1
and DDRII2 memory sockets.
