61" cutting deck – Great Dane Chariot Brutus GBKW2552S User Manual
Page 83
61" CUTTING Deck - 81
61" CUTTING DECK
Ref. No.
Part No.
Description
Qty.
Remarks
1
GDA10077
MOWER DECK
1
61"
2
D18211
PULLEY
3
CUTTER HOUSING 61"
3
D13024
SPACER
3
4
D13055
NUT
3
5
200041
SPINDLE
3
6
19M7786
BOLT
18
M10 X 1.5 X30 HHFCS
7
E63526
NUT
18
M10 X 438 HHSFN
8
D18055
SPACER
9
9
967347
BOLT
3
5/8-11 X 2.25
10
14H1083
NUT
3
5/8"
11
GDU10232
BLADE
3
61" HIGH LIFT
12
TCU14540
BUSHING
2
13
GDU10119
STRAP
1
14
E62934
FLANGE NUT
4
15
TCU18744
WHEEL
6
GAGE
16
D24040
BOLT
4
17
GDU10187
COVER
1
LH 61"
18
M119352
KNOB
2
19
GDA10084
ARM
1
LH
20
GDA10085
ARM
1
RH
21
D18076
BUSHING
4
22
JD7844
LUBRICATION FITTING
3
23
19H2380
SCREW
2
1/4" X 1"
24
D24008
LOCK NUT
2
25
TCA13292
PIN FASTENER
2
26
03M7185 BOLT
2
M8
X
25
27
14M7396
LOCK NUT
2
M8
28
GDA10103
PIVOT
2
29
03H1729
BOLT
2
1/4" X 1
30
H122207
FLANGE NUT
2
31
TCA15346 ARM
1
32
D18032
PULLEY
1
33
03H1658
BOLT
1
3/8" X 2-1/4"
34
24H1305
WASHER
1
13/32" X 13/16" X .065"
35
K40003
LOCK NUT
4
36
03H1836
BOLT
1
3/8" X 3-1/2"
37
AM127488
CHUTE
1
38
M132768
TORSION SPRING
1
39
H141123
PUSH NUT
1
40
03H2040
BOLT
1
41
D23058
HOOK BOLT
1
61"
42
D28025
SPRING
1
43
D14010
LOCK NUT
1
44
N10215
LOCK NUT
1
45
TCA14548
PULLEY
1
46
GDU10180
SPACER
1
47
03H1838
BOLT
1
3/8" X 5"
48
D28050
IDLER
1
49
GDU10181
SPACER
1
