Great Dane Chariot Brutus GBKW2552S - Manual (Page 55)

ENGINE AND RELATED COMPONENTS - KAWASAKI - 53
ENGINE AND RELATED COMPONENTS - KAWASAKI
Ref. No. Part No. Description Qty. Remarks
1 14M7166 LOCK NUT 4 M8
2 19M7897 SCREW 4 M8 X 35
3 200318 PULLEY 1 ENGINE TO PUMP
4 GDA10017 CLUTCH 1 MAG-STOP ELECTRIC
5 D18056 SPACER 1
6 D14208 LOCK WASHER 1
7 19H2531 CAP SCREW 1 7/16" X 3"
8 TCA16240 DRAIN VALVE 1
9 D18145 SHAFT KEY 1
10 D18379 CLAMP 1
11 M76926 TUBE 1
12 M78480 TIE BAND 2
13 M136651 GASKET 2 25 HP
14 GD10128 MUFFLER 1 25 HP
15 H137328 LOCK NUT 2
16 03M7184 BOLT 2 M8 X 20
17 D22236 ANGLE 1
18 12M7065 LOCK WASHER 4 M8
19 14M7273 NUT 4 M8
20 200316 BRACKET 1
21 03M7017 BOLT 2 M10 X 25
22 14M7518 FLANGE NUT 2 M10
