Great Dane Chariot Brutus GBKW2552S User Manual
Page 65
Hydrostatic drive system Components - 63
HYDROSTATIC DRIVE SYSTEM COMPONENTS
NOTES
Ref. No.
Part No.
Description
Qty.
Remarks
1
D24028
FITTING
6
2
BULK HOSE
AR
(21") CASE RETURN, (MAKE FROM TY22503)
3
BULK HOSE
AR
(5") CASE RETURN, (MAKE FROM TY22503)
4
BULK HOSE
AR
(11-1/4") CASE RETURN, (MAKE FROM TY22503)
5
BULK HOSE
AR
(11-1/4") CHARGE INLET, (MAKE FROM TY22503)
6
BULK HOSE
AR
(5") CHARGE INLET, (MAKE FROM TY22503)
7
BULK HOSE
AR
(29") CHARGE INLET, (MAKE FROM TY22503)
8
D18379
CLAMP
12
9
D14197
FITTING
4
10
M86863
TEE FITTING
2
11
D28026
HOSE
2
HIGH PRESSURE (SHORT)
12
GDA10089
HYDRAULIC HOSE
2
HIGH PRESSURE (LONG)
13
D24026
FITTING
4
14
MT2119
NUT
2
PATCH LOCK
15
200313
PUMP
1
HYDROSTATIC (BDP - 12) RH
16
200312
PUMP
1
HYDROSTATIC (BDP - 12) LH
D19000
SEAL KIT
1
17
GDA10022
DIPSTICK
1
18
TCA15373
HYDRAULIC RESERVOIR
1
19
D18207
KEY
2
20
GDA10137
OIL FILTER
1
21
GDA10100
WHEEL MOTOR
2
AZ45116
GASKET KIT
1
M78480
TIE BAND
4
