H8153 DC Stick/TIG Pulse Welder
Safety labels warn about machine hazards and ways to prevent injury. The owner of this welder
MUST maintain the original location and readability of the labels on the welder. If any label is
removed or becomes unreadable, REPLACE that label before using the welder again. Contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
Replacement Parts & Labels
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH8153001 GAS INLET TUBE 10 PH8153010 COLLET 2MM
2 PH8153002 COLLET BODY 11 PH8153011 TIG TORCH & CABLE ASSEMBLY
3 PH8153003 GAS NOZZLE #4 12 PH8153012 WORK CLAMP & CABLE
4 PH8153004 GAS NOZZLE #5 13 PH8153013 ELECTRODE CLAMP & CABLE
5 PH8153005 GAS NOZZLE #6 14 PLABEL-14 ELECTRICITY LABEL
6 PH8153006 LONG COLLET BACKCAP 15 PLABEL-12 READ MANUAL LABEL
7 PH8153007 SMALL COLLET BACKCAP 16 PH8153016 WELDER ID LABEL
8 PH8153008 COLLET 1.6MM 17 PH8153017 SHOCK WARNING LABEL
9 PH8153009 COLLET 1.8MM
17
16
15
14
12
11
10
9
8
7
6
5
4 3
2
1
13
