-20- G4227 Sliding Table
REF PART # DESCRIPTION REF PART # DESCRIPTION
42 PLW02 LOCK WASHER 1 ⁄
4
"
43 P4227043 WORK TABLE
44 P4227044 SCREW 3 ⁄
8
"
45 P4227045 DEGREE SCALE
46 P4227045 BUSHING
47 P4227047 SPACER
48 P4227048 ECCENTRIC BUSHING
49 P4227048 BUSHING MOUNT BRACKET
50 P4227050 SCREW 1 ⁄
2
"
51 PW06 FLAT WASHER 1 ⁄
4
"
52 PSB05 CAP SCREW 1 ⁄
4
"-20 X 3 ⁄
4
"
53 PSS03 SETSCREW 1 ⁄
4
"-20 X 3 ⁄
8
"
54 P4227054 T-BOLT, LONG
55 P4227055 BRACKET
56 PN05 HEX NUT 1 ⁄
4
"-20
57 PB31 HEX BOLT 1 ⁄
4
"-20 X 1"
59 P4227059 SHAFT
60 P4227060 SLIDING BRACKET
61 P4227061 LOCKING BRACKET
63 P4227063 LOCK HANDLE
64 PB51 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
8
"
65 PW02 FLAT WASHER 3 ⁄
8
''
66 P4227066 STUD
67 P4227067 BOTTOM BRACKET
68 P4227068 BOTTOM RAIL
69 P4227069 PLUG
70 PN02 HEX NUT 5 ⁄
16
"-18
71 P4227071 HANDLE
72 P4227072 SUPPORT BRACKET
73 PN13 HEX NUT 1 ⁄
2
"-13
74 PLW07 LOCK WASHER 1 ⁄
2
"
75 P4227075 BEARING BRACKET
76 P4227076 SPACER
77 P6304 BEARING 6304-2RS
78 P4227078 AXLE
79 PB05 HEX BOLT 1 ⁄
4
''-20 X 3 ⁄
4
''
80 PW07 FLAT WASHER 5 ⁄
16
''
81 PB03 HEX BOLT 3 ⁄
4
"-18 X 1''
1 PS13 PHLP HD SCR 10-24 X 1 1 ⁄
4
''
2 PW03 FLAT WASHER #10
3 P4227003 STOP
4 P4227004 LOCK HANDLE
5 PW16 FLAT WASHER #6
6 P4227006 STOP BRACKET
7 P4227007 POINTER
8 PS16 PHLP HD SCR 6-32 X 1 ⁄
4
''
9 P4227009 GIB BOLT
10 P4227010 SCALE
11 P4227011 FENCE
12 PSB11 CAP SCREW 5 ⁄
16
"-18 X 1 1 ⁄
4
''
13 PN07 HEX NUT 10-24
14 P4227014 TOP RAIL BRACKET
15 PLW04 LOCK WASHER 3 ⁄
8
''
16 P4227016 CAP SCREW 3 ⁄
8
''- 16 X 2 3 ⁄
8
''
17 P4227017 END CAP
18 P4227018 TOP RAIL
19 P4227019 SPACER
20 PS22 PHLP HD SCREW 10-24 X 5 ⁄
8
''
21 P4227021 IDLER WHEEL W⁄BUSHING
22 P4227022 RUBBER RING
23 P4227023 FRONT STOP
26 PR01M SNAP RING 10MM
27 P6200 BEARING 6200-2RS
28 P4227028 BEARING SHAFT
29 P4227029 T-BOLT, SHORT
30 PW02 FLAT WASHER 3 ⁄
8
''
32 P4227032 LOCK HANDLE
33 PLW03 LOCK NUT 5 ⁄
16
" - 18
34 P609 BEARING 609-2RS
35 P4227035 V-ROLLER
36 PSS03 SETSCREW 1 ⁄
4
"-20 x 3 ⁄
8
"
37 P4227037 ECCENTRIC SHAFT
38 P4227038 TABLE FRAME
39 P4227039 CAP SCREW M10-1.5 x 55
40 PN08 HEX NUT 3 ⁄
8
" - 16
41 PSB04 CAP SCREW 1 ⁄
4
" - 20 x 1 ⁄
2
"
