39
3 Squeeze the two clips on the sides of the fan (1) together to release it, then lift it out of the
fan cage.
4 Insert the replacement fan into the fan cage until it clicks into place.
5 Follow the instructions in “Closing the server case” on page 26 .
Replacing the fan cage and fan board
To replace the fan cage and the fan board:
1 Follow the instructions in “Preventing static electricity discharge” on page 24 . Make sure
that you turn off the server, then unplug the power cord(s) and all other cables connected
to the server.
2 Follow the instructions in “Opening the server case” on page 25 .
3 Remove the system fans by following the instructions in “To replace a system fan:” on
page 38 .
4 Loosen the two screws (2) on the sides of the fan cage, then lift the fan cage (3) out of the
chassis.
5 Remove the cables from the fan board.
