CHAPTER 4: Installing Components

34

DIMM banks must be populated using the following guidelines:

Caution

All DIMMs installed must be the same speed. Do not install more than four dual rank

DIMMs or the BIOS will generate a memory configuration error

.

DIMM Installation Options - Non-redundant Mode

DIMM

DIMM1

DIMM2

DIMM3

DIMM4

DIMM5

DIMM6

DIMM7

DIMM8

Total Usable

Memory

1

512 MB

-

512 MB

1 GB

-

1 GB

2 GB

-

2 GB

4 GB

-

4 GB

2

512 MB

-

512 MB

-

1 GB

-

1 GB

-

2 GB

-

2 GB

-

4 GB

-

4 GB

-

8 GB

4

512 MB

-

2 GB

1 GB

-

4 GB

2 GB

-

8 GB

4 GB

-

16 GB

512 MB

-

512 MB

-

512 MB

-

512 MB

-

2 GB

1 GB

-

1 GB

-

1 GB

-

1 GB

-

4 GB

2 GB

-

2 GB

-

2 GB

-

2 GB

-

8 GB

4 GB

-

4 GB

-

4 GB

-

4 GB

-

16 GB

8

512 MB

4 GB

1 GB

8 GB

2 GB

16 GB

4 GB

32 GB

DIMM Installation Options - Mirrored Mode

DIMM

DIMM1

DIMM2

DIMM3

DIMM4

DIMM5

DIMM6

DIMM7

DIMM8

Total Usable

Memory

4

512 MB

-

512 MB

-

512 MB

-

512 MB

-

1 GB

-

1 GB

-

1 GB

-

1 GB

-

2 GB

-

2 GB

-

2 GB

-

2 GB

-

4 GB

-

4 GB

-

4 GB

-

4 GB

-

8 GB
