Direct Drive - Level 2
Model SE2 for exhaust — Model SS2 for supply
Performance certified is for Models SE2/SS2 for installation type A: free inlet, free outlet. Power rating (BHP) does not include transmission losses.
Performance ratings do not include the effects of appurtenances (accessories).
* Speed (RPM) shown is nominal. Performance is based on actual speed of test.
The sound ratings shown are loudness values in fan sones at 5 ft (1.5 m) in a hemispherical free field calculated per AMCA Standard 301. Values are for installation
type A: free inlet hemispherical sone levels.
Numbers in blue have a larger BHP and require the next size larger motor.
Model Number
Motor
HP
Fan
RPM
Max
BHP
Sones
@ F.A.
CFM / Static Pressure in Inches WG
0.00 0.10 0.125 0.15 0.20 0.25 0.30 0.375 0.50 0.625 0.75 1.00
SE2 / SS2 Performance Limits
SE2/SS2-16-427-B6
1/6 1160
0.15 11.3 2213 1933 1849 1766 1536 1215 894
SE2/SS2-16-435-B6 0.20 11.6 2522 2239 2150 2055 1732 1434
SE2/SS2-16-417-A4 1/4
1750
0.30 18.7 2582 2414 2375 2336 2255 2156 2053 1869 1435 1084
SE2/SS2-16-423-A3 1/3 0.38 19.9 3076 2899 2854 2809 2719 2621 2524 2331 1916
SE2/SS2-16-430-A5 1/2 0.56 23 3531 3344 3297 3250 3155 3058 2944 2750 2303 1642
SE2/SS2-18-423-B6 1/6
1160
0.20 12.5 2917 2632 2562 2458 2249 2018
SE2/SS2-18-430-B4 1/4 0.29 14.2 3376 3038 2944 2861 2662 2398 2084
SE2/SS2-18-435-B3 1/3 0.35 16.2 3658 3311 3208 3089 2850 2556 1903
SE2/SS2-18-411-A4 1/4
1750
0.30 21 3121 2978 2941 2893 2799 2697 2586 2415
SE2/SS2-18-415-A3 1/3 0.41 22 3623 3476 3439 3400 3300 3199 3091 2920
SE2/SS2-18-421-A5 1/2 0.59 22 4177 4015 3975 3931 3807 3683 3574 3416 3059 2558
SE2/SS2-20-420-B6 1/6
1160
0.21 15.3 3697 3350 3257 3137 2857 2532 2155
SE2/SS2-20-423-B4 1/4 0.30 17.2 3997 3626 3522 3419 3153 2834 2430
SE2/SS2-20-430-B3
1/3
0.40 18.6 4468 4087 3989 3882 3626 3281
SE2/SS2-20-407-A4
1750
0.37 27 3579 3382 3333 3282 3180 3053 2922 2744 2300 1869 1342
SE2/SS2-20-410-A3 0.37 28 4035 3835 3785 3731 3623 3461 3254 3113 2791
SE2/SS2-20-415-A5 1/2 0.57 29 4934 4697 4637 4578 4454 4330 4185 3957
SE2/SS2-20-420-A7 3/4 0.88 30 5577 5355 5300 5243 5121 4999 4877 4614 4138 3544 2992
SE2/SS2-20-427-A10 1 1.19 33 6633 6364 6297 6231 6099 5968 5837 5613
SE2/SS2-20-435-A15 1 1 ⁄
2
1.76 35 7266 6980 6909 6837 6691 6543 6396 6115 5453 4658
SE2/SS2-24-615-C4 1/4
860
0.28 15.7 4687 4200 4058 3895 3561 3126 2488
SE2/SS2-24-620-C3 1/3 0.36 18.5 5300 4710 4557 4410 3993 3445 2607
SE2/SS2-24-630-C5 1/2 0.54 18.8 6439 5768 5599 5412 4993 4387
SE2/SS2-24-620-B7 3/4
1160
0.86 23 7148 6728 6619 6502 6268 6049 5831 5308 4315
SE2/SS2-24-625-B10 1 1.13 25 7917 7491 7391 7291 7060 6781 6501 6035 4850 2745
SE2/SS2-24-600-A7 3/4
1750
0.87 36 5070 4877 4828 4778 4676 4573 4455 4251 3911 3518 3161 2287
SE2/SS2-24-604-A10 1 1.18 39 6297 6081 6027 5973 5865 5747 5627 5447 5084 4671 4203
SE2/SS2-24-610-A15 1 1 ⁄
2
1.70 40 8137 7904 7845 7787 7670 7559 7448 7281 6968 6571 6178 5106
SE2/SS2-24-615-A20 2 2.28 41 9537 9310 9253 9197 9083 8961 8835 8646 8315 7915 7508 6559
SE2/SS2-30-618-C7 3/4
860
0.79 23 9698 9066 8886 8707 8309 7892 7340 6370
SE2/SS2-30-625-C10 1 1.18 28 11515 10823 10644 10461 10097 9629 9051 7945
SE2/SS2-30-635-C15 1 1 ⁄
2
1.80 32 13290 12505 12291 12076 11647 11060 10192 7951
SE2/SS2-30-605-B7 3/4
1160
0.86 29 7911 7479 7369 7257 7034 6795 6551 6210 5496 4497 3377
SE2/SS2-30-610-B10 1 1.17 30 9662 9293 9201 9103 8872 8640 8392 7976 7204 6248 5108
SE2/SS2-30-615-B15 1 1 ⁄
2
1.72 31 12000 11565 11456 11348 11130 10890 10619 10200 9404 8327 6921
SE2/SS2-30-620-B20 2 2.29 33 13905 13434 13316 13198 12939 12665 12391 11954 11144 10136 8640
SE2/SS2-36-607-C7 3/4
860
0.82 27 9985 9347 9183 9012 8669 8255 7829 7039 5325 3679 2486
SE2/SS2-36-611-C10 1 1.11 30 12131 11529 11360 11187 10840 10449 10058 9289 7622 5532 3782
SE2/SS2-36-617-C15 1 1 ⁄
2
1.61 31 15162 14491 14324 14153 13810 13442 12926 12117 10512 7704 5270
SE2/SS2-36-600-B10 1
1160
1.21 34 8200 7791 7656 7515 7224 6913 6617 6214 5478 4679 3902
SE2/SS2-36-605-B15 1 1 ⁄
2
1.72 36 11977 11535 11424 11313 11077 10828 10580 10147 9384 8487 7337 5080
SE2/SS2-36-609-B20 2 2.34 37 14957 14468 14345 14223 13976 13728 13480 13098 12411 11537 10483 7678
SE2/SS2-36-614-B30 3 3.29 40 18400 17945 17832 17718 17490 17263 16965 16517 15787 15003 13722 10993
SE2/SS2-42-602-C10 1
860
1.08 30 8673 7991 7811 7632 7254 6888 6531 5979 4937 3944 2850
SE2/SS2-42-608-C15 1 1 ⁄
2
1.73 32 14642 14035 13883 13732 13396 13058 12692 12072 10980 9558 8035
SE2/SS2-42-612-C20 2 2.42 33 18363 17675 17503 17331 16966 16600 16233 15619 14477 13041
SE2/SS2-42-617-C30 3 3.32 35 21840 21148 20975 20802 20440 20032 19624 18975 17694 16259 14629 8191
SE2/SS2-42-627-C50 5 5.95 41 28811 27924 27702 27480 27037 26533 26023 25261 24002 22494 20376 13589
SE2/SS2-48-407-C15 1 1 ⁄
2
860
1.84 43 18124 17081 16823 16565 16049 15499 14820 13815 12067 9984 7536
SE2/SS2-48-410-C20 2 2.40 44 21801 20853 20616 20362 19848 19333 18699 17684 15807 13843 11719
SE2/SS2-48-415-C30 3 3.58 48 27004 26027 25783 25539 24915 24272 23638 22726 21025 19172 16924
SE2/SS2-48-422-C50 5 5.91 53 34332 33166 32874 32583 31944 31257 30570 29594 27990 25869 23518
SE2/SS2-54-420-F50
5
690 5.76 52 41542 39736 39284 38845 38011 37177 36322 34995 32089 28911 25289 14535
SE2/SS2-54-410-C50
860
5.68 53 35642 34502 34217 33932 33364 32826 32287 31334 29690 27722 25548 20120
SE2/SS2-54-416-C75 7 1 ⁄
2
8.68 54 45612 44465 44179 43892 43319 42745 42051 40967 39103 37130 34973 30171
