Page 16
16
Panel/Drive frame - Galvanized steel with one-piece
drawn venturi, bolted structural steel channels and
motor plate (paint optional).
Propeller - Heavy duty, welded and gusseted painted
steel.
Motors - Heavy duty, permanently lubricated, ball
bearing type.
Material Gauges
Max.
Motor
Frame
Size
Approx.
Weight
(lbs.)
Fan
Size
Fan
Panel
Drive
Frame
Prop
Hub
Prop
Blade
16
18
14
14
16
56
40
18
18
14
14
16
56
45
20
18
12
14
16
145T
60
24
18
12
14
16
145T
85
30
16
12
12
16
184T
130
36
16
12
12
16
215T
230
42
14
10
11
14
254T
290
48
14
10
11
14
254T
375
54
14
10
10
14
256T
465
Approximate weight does not include accessories.
Fan
Size
A Panel**
B*
C*
D
E
F*
Damper
Size**
16
22 (559)
13
1
⁄
2
(343)
10
1
⁄
4
(260)
1 (25)
16
3
⁄
8
(416)
14 (356)
18 (457)
18
24 (610)
13
1
⁄
2
(343)
10
1
⁄
4
(260)
1 (25)
18
3
⁄
8
(467)
14
1
⁄
4
(362)
20 (508)
20
26 (660)
17
1
⁄
4
(438)
13
1
⁄
2
(343)
1 (25)
20
1
⁄
2
(521)
18 (457)
22 (559)
24
32 (813)
20 (508)
13
1
⁄
2
(343)
1
1
⁄
4
(32)
24
5
⁄
8
(625)
21 (533)
26 (660)
30
38 (965)
20
1
⁄
2
(521)
16
3
⁄
8
(416)
1
1
⁄
4
(32)
30
5
⁄
8
(778)
21
3
⁄
4
(552)
32 (813)
36
44 (1118)
20
1
⁄
2
(521)
16
3
⁄
8
(416)
2 (51)
36
5
⁄
8
(930)
28 (711)
38 (965)
42
50 (1270)
26 (660)
18
1
⁄
4
(464)
2 (51)
42
5
⁄
8
(1083)
28 (711)
44 (1118)
48
56 (1422)
26
5
⁄
8
(676)
20
5
⁄
8
(524)
2 (51)
49
1
⁄
4
(1251)
28
1
⁄
2
(724)
50 (1270)
54
62 (1575)
28 (711)
22
7
⁄
16
(570)
2 (51)
55
3
⁄
8
(1407)
30
1
⁄
8
(765)
56 (1422)
* Varies with motor selection. All dimensions given in inches (mm). **Square dimension.
Direct Drive - Level 2
Dimensional Data: Models SE2/SS2
All direct drive models are available in either exhaust (Model SE2) or supply (Model SS2) arrangements.
E
F*
D
B*
C*
D
A Sq.
Airflow
Exhaust
Airflow
Supply
Model SE2 exhaust shown
