MM-4000
FADER REPLACEMENT: SPECIFICATIONS:
1. UNSCREW THE FADER (B) SCREWS. DO NOT TOUCH INSIDE
SCREWS (C) CAREFULLY REMOVE OLD CROSS FADER AND UNPLUG
CABLE (D)
2. PLUG IN THE NEW CROSS
FADER INTO CABLE (D) AND
PLACE BACK INTO MIXER.
3. SCREW THE CROSS FADER TO
MIXER WITH THE FADER PLATE
SCREWS (B)
4. REPLACE THE FACE OF THE
MIXER AND SCREW THE FOUR
SCREWS BACK IN AND REPLACE THE FADER KNOBS.
6
INPUTS:
Phono.....................................................................................3mV,47 KOhm
Line..................................................................................150 mV, 27 KOhm
MIC......................................................................1.5 mV, 1 KOhm Balanced
OUTPUTS:
Max...................................................................................20V Peak-to Peak
Rec.....................................................................................225 mV, 5 KOhm
GENERAL:
Frequency Response...............................................20Hz - 20KHz +/- 0.5dB
Distortion..........................................................................................< 0.02%
S/N Ratio...........................................................................Better than 85 dB
Headphone impedance.....................................................................32 Ohm
Power Source ..........................................................115/230v,50/60Hz,20w
Unit Demensions........................................................................19” x 7” x 3”
.......................................................................................(483 x 178 x76mm)
Weight................................................................................10 lbs (4.53 kg)
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTIFICATION FOR IMPROVEMENT
