Page 5

CONTROLS:

(CONTINUED)

3 BAND EQUALIZER
The

3 BAND EQUALIZER adjust the tone of each CHANNEL by

giving you a choice 3 frequencies (

BANDS) to adjust , from LOW,

MIDRANGE (MID) and HIGH’s ,you can use the adjustment knobs to
higher or lower the 3 separate frequencies till the sound of the music
program is appropriate for your listening environment.

EFFECT ASSIGN
The

EFFECT ASSIGN buttons allow you to choose which channel

(

LINE or MIC) will be sent to the effects section, either one or all

channels can be selected at once (

see effects section).

CHANNEL CUE SELECTOR
The

CHANNEL CUE SELECTOR allows you to choose which

channel will be heard in the headphones, one or all can be pressed at
the same time, when pressed a red LED will illuminate indicating the
CUE is in the ON position

CHANNEL VOLUME FADER
After you have chosen which input you will use with the

INPUT

SELECTOR the corresponding CHANNEL FADER will allow you to
adjust the volume for that particular

CHANNEL.

CROSSFADER ASSIGNMENT
The fader assignment rotary allows you to assign which two of the

channels will be controlled by the

CROSSFADER.There are 5

selections for either side of the

CROSSFADER which can be either

CHANNEL 1,2,3,4 or OFF, In the OFF position the CROSSFADER
will not affect the volume of any

CHANNEL.

CROSSFADER
The

CROSSFADER allows you to mix evenly from one source to

another. On the

MM-4000 The CROSSFADER is assignable between

either channels (

1) and (2) or channels (3) and (4) depending on the

position of the fader assignment push button (see above).
The

CROSS FADER on the MM-4000 is also removable and if the

need arises can be replaced.The

RG-45 (RAILGLIDE™)

DUAL-RAIL CROSS FADER, which has internal dual stainless steel
rails that allow the slider to ride smoothly and accurately from end to
end can be purchased from your local

GEMINI dealer.

NOTE: WHEN USING THE CROSS FADER LIGHTLY GLIDE THE FADER BACK AND

FORTH. PRESSING DOWN ON THE CONTROLS CAN BEND CONTACTS AND CAUSE A
LOSS OF SOUND.

CUE/PGM FADER
The

CUE/PGM FADER determines the mix between the chosen

CHANNEL CUE SELECTION and the MAIN OUTPUT mix.
To the left is the

CUE program and to the right is MAIN OUTPUT.

POWER SWITCH
Main

POWER switch (see above).

VU METER
The

MM-4000 has a VU METER that allows you to monitor the

decibel levels of the

LEFT and RIGHT MASTER output.

It also has two settings

(SEE BELOW)

VU METER SETTING SWITCH
The

VU SETTING SWITCH allows you to choose between two VU

display modes, In the

CUE position the VU will display the levels of

the headphone

CUE, and in the MASTER position the VU will display

the

MASTER output levels.

MONO/STEREO
The

MONO/STEREO switch allows you to change the output of the

MM-4000 to either MONO output or STEREO output depending on
the nature of the system you are playing through, for example some
nightclub systems are wired in

MONO, this switch gives you the

choice to change the output of the

MM-4000 to either MONO or

STEREO.

MM-4000

ON/OFF
Turns the effect section

ON or OFF.

WET/DRY ROTARY
Adjusts the mix between the (

DRY) input signal being sent from the

effect assigned channels and the processed (

WET) signal coming

from the effects section.

CUE EFX BUTTON
Like the

CUE SELECT BUTTONS the CUE EFX BUTTON lets you

monitor the effect in the headphone before you mix it in using
DRY/WET ROTARY.

EFFECT SELECTION ROTARY
Lets you choose between the 16 different built in effect choices
which consist of:

ROOM REVERB:
A short

REVERB that mimics the sound of being in a small ROOM

this

REVERB has three (3) different settings.

PLATE REVERB:
An artificially created

REVERB that uses a plate of metal to

simulate a highly reflective

ROOM sound, this REVERB also has

three (3) different settings.

HALL REVERB:
Is a longer

REVERB that mimics the sound of being in a concert

HALL this also has three (3) different settings.

ECHO:

ECHO is similar to a delay effect which basically repeats the sound
and then decays or trails it out mimicing the sound of a canyon or
very large area with reflective qualities, this

EFFECT also has three

(3) different settings.

VOCAL CANCELLATION:
Can be used to cancel or remove the vocals in a song so you can
sing over it.

AUTO WAH:
Is a

FILTER that automatically opens and closes giving you the

sound similar to that of a

WAH WAH pedal used with guitars.

FLANGER:
A

FLANGER sounds like two records being played at the exact same

time, which give you a tunnel or jet plane type of sound.

AUTO PAN:

AUTO PAN will automaticaly pan the sound from the left speaker to
the right speaker at a pre-determined tempo.

EFFECTS:

ZONE VOLUME ROTARY
Controls the volume level of the

ZONE OUTPUT .

MASTER VOLUME ROTARY
The

MASTER VOLUME ROTARY knob adjust the volume of the

MAIN OUTPUT.

CUE VOLUME ROTARY KNOB
The

CUE VOLUME ROTARY KNOB adjusts your HEADPHONE

MONITOR OUTPUT volume.
