GA-K8N51PVMT-9-RH Motherboard - 52 -
English
3-6 Connecting the Video Output Devices
Step 1:
(The following procedure uses HDTV setup as an
example)
After installation of the motherboard driver, right-
click on Desktop and select Properties. When
Display Properties dialog box appears, select
the Settings tab. In Settings, click the Advanced
button.
Step 2:
Click the GeForce 6150 tab when advanced prop-
erties dialog box appears. Select nView Display
Settings from the side menu and select HDTV
from the Current display list. Then click Apply.
Step 3:
Right-click on the HDTV icon and select TV format
depending on your HDTV. Then click Apply to
complete the settings.
Connect the video output devices to the video adapter according to the corresponding jack, then refer
to the following steps to configure the driver settings.
HDTV
NTSC/PAL TV
Projector
Pb/AV
Pr
Y
S-Video Output
Video Adapter
TV Out Port
