H6239 Parts Breakdown and List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH6239001 FRAME 9 PH6239009 AXLE SLEEVE
2 PH6239002 RAM BRACKET 10 PH6239010 COTTER PIN
3 PH6239003 PIN SLEEVE 11 PH6239011 WHEEL
4 PH6239004 PIN 12 PB32M HEX BOLT M10-1.5 X 25
5 PH6239005 U-CLAMP 13 PW04M FLAT WASHER 10MM
6 PH6239006 EXTENSION SPRING 14 PLW06M LOCK WASHER 10MM
7 PH6239007 RAM 15 PN02M HEX NUT M10-1.5
8 PH6239008 AXLE 16 PH6239016 ADVANCE�PUMP�HANDLE
17 PH6239017 OIL SEAL
18 PH6239018 SPLITTING�PUMP�HANDLE
