58 - English
9. TROUBLE SHOOTING
9.2 Indicator lamp in the charging station
For a fully functional installation, the indicator lamp in the charging station must emit a solid green light. If
something else appears, follow the troubleshooting guide below.
There is more troubleshooting help on www.gardena.com/int. If you still need help with troubleshooting,
please contact GARDENA Central Service. See MEMO on page 4.
Light Cause Action
Solid green light Everything in order No action required
Blue flashing light The boundary loop is not connected
to the charging station Check that the boundary wire
connector is fitted properly to the
charging station. See 3.5 Connecting
the boundary wire on page 26.
Break in the boundary loop Find out where the break is. Replace
the damaged section of the loop with
a new loop wire and splice using an
original coupler. See 9.4 Finding
breaks in the loop wire on page 61.
Yellow flashing light The guide wire is not connected to
the charging station Check that the guide wire connector
is properly connected to the charging
station. See 3.6 Installation of the
guide wire on page 27.
Break in the guide wire Find out where the break is. Replace
the damaged section of the loop with
a new loop wire and splice using an
original coupler.
Red flashing light Interruption in the charging station’s
antenna Contact GARDENA Central Service.
See MEMO on page 4.
Blue solid light Weak signal as the boundary wire is
too long. Max length is 250 metres. No steps have to be taken if the
R40Li operates as expected.
Shorten the boundary wire by
reducing the working area or
replacing islands with barriers the
mower can collide with.
Weak signal due to damaged
boundary wire Since it is difficult to locate where the
wire is damaged it is recommended
to lay a new boundary wire for the
entire working area.
Red solid light Defective circuit card in the charging
station Contact GARDENA Central Service.
See MEMO on page 4.
