Protection Connector Pin-Out
The Protection connector for is an Rj-45, 8-pin, male type connector.
Pin
Left Right
Function
1 1
GND
2 5
E_SLF_OUT
3 6
IDC
TXD
4 7
Cable
Echo
5 2
E_MT_IN
6 3
IDC
RXD
7 4
NA
8 8
GND
8 x E1/T1 Connector Pin-Out
The 8 x E1/T1 connector is a 36-pin connector.
Connector
Pin #
Signals Color
Connector
Pin #
Signals Color
11
OUT - TIP 1
Brown/Red
1
IN - TIP 1
Blue/White
29
OUT - RING 1
Red/Brown
TWISTED
PAIR
19
IN - RING 1
White/Blue
TWISTED
PAIR
12
OUT - TIP 2
DarkBlue/Red
2
IN - TIP 2
Orange/White
30
OUT - RING 2
Red/DarkBlue
TWISTED
PAIR
20
IN - RING 2
White/Orange
TWISTED
PAIR
13
OUT - TIP 3
Blue/Black
3
IN - TIP 3
Green/White
31
OUT - RING 3
Black/Blue
TWISTED
PAIR
21
IN - RING 3
White/Green
TWISTED
PAIR
14
OUT - TIP 4
Orange/Black
4
IN - TIP 4
Brown/White
32
OUT - RING 4
Black/Orange
TWISTED
PAIR
22
IN - RING 4
White/Brown
TWISTED
PAIR
15
OUT - TIP 5
Green/Black
5
IN - TIP 5
DarkBlue/White
33
OUT - RING 5
Black/Green
TWISTED
PAIR
23
IN - RING 5
White/DarkBlue
TWISTED
PAIR
16
OUT - TIP 6
Brown/Black
6
IN - TIP 6
Blue/Red
34
OUT - RING 6
Black/Brown
TWISTED
PAIR
24
IN - RING 6
Red/Blue
TWISTED
PAIR
17
OUT - TIP 7
DarkBlue/Black
7
IN - TIP 7
Orange/Red
35
OUT - RING 7
Black/DarkBlue
TWISTED
PAIR
25
IN - RING 7
Red/Orange
TWISTED
PAIR
18
OUT - TIP 8
Blue/Yellow
8
IN - TIP 8
Green/Red
36
OUT - RING 8
Yellow/Blue
TWISTED
PAIR
26
IN - RING 8
Red/Green
TWISTED
PAIR
9,10 Shell
(1)
-
SHIELD
