English – GIGABYTE Pentium 4/D Processor Motherboard GA-5EASV-RH User Manual
Page 12
1 2
English
GA-5EASV-RH Motherboard
2-2: Install Memory Modules
GA-5EASV-RH has 4 dual inline memory module (DIMM) sokcets. It supports Dual Channels
Technology. The BIOS will automatically detects memory type and size during system boot. For detail
DIMM installation, please refer to the following instructions.
Before installing the processor and heatsink, adhere to the following warning:
When DIMM LED is ON, do not install/remove DIMM from socket.
Channel A
(Yellow)
Channel B (Red)
