Grandstream Networks, Inc. GXP User Manual Page 26 of 38
Firmware 1.1.5.15 Last Updated: 12/2007
Table 13: Device Configuration - Status
Hardware Revision Hardware version number: Main Board, Interface Board
MAC Address The device ID, in HEXADECIMAL format.
IP Address This field shows IP address of GXP
Product Model This field contains the product model information.
Software Version • Program: This is the main software (firmware) release number, always used to
identify the software (firmware) system of the phone.
• Boot: Booting code version number
System Up Time This field shows system up time since the last reboot.
Registered Indicates whether accounts are registered to the related SIP server(s). GXP can
support four unique SIP profiles.
PPPoE Link Up Indicates whether the PPPoE connection is enabled (connected to a modem).
Table 14: Device Configuration – Basic Settings
End User
Password This contains the password to access the Web Configuration Menu. This field is
case sensitive with a maximum length of 25 characters.
IP Address There GXP operates in two modes:
1. DHCP mode: all the field values for the Static IP mode are not used (even
though they are still saved in the Flash memory.) The GXP acquires its IP
address from the first DHCP server it discovers on its LAN. The DHCP
option is reserved for NAT router mode. To use the PPPoE feature, set the
PPPoE account settings. The GXP establishes a PPPoE session if any of
the PPPoE fields are set.
2. Static IP mode: configure all of the following fields: IP address, Subnet
Mask, Default Router IP address, DNS Server 1 (primary), DNS Server 2
(secondary). These fields are set to zero by default.
Multi Purpose Key X These options are used to assign a function to the corresponding multi purpose key.
Options available are: “Speed Dial”, “BLF”, “Presence Watcher” and “Eventlist BLF”.
Each function is connected to one of the accounts and has a target user ID.
Time Zone This parameter controls the date/time display according to the specified time zone.
LCD Backlight Always
On Turn on LC backlight at all times. Default is No. This option applies to GXP-
1200/GXP-2000 only.
Time Display Format LCD time display in 12 hour or 24 hour format
Date Display Format Choose one of the following formats:
• Year-Month-Day
• Month-Day-Year
• Day-Month-Year
This option applies to GXP-1200/GXP-2000 only.
