H7945/H7946/H7995 26° Angle Nailer -19 -
H7995 PARTS LIST
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PFH43M FLAT HD SCR M6-1 X 10 47 PH7945047 MAGAZINE COVER
2 PH7945002 EXHAUST COVER 48 PH7945048 NAILER GUIDE
3 PSB53M CAP SCREW M5-.8 X 18 49 PSB33M CAP SCREW M5-.8 X 12
4 PH7945004 CAP 50 PH7945050 CONTACT ARM
5 PH7945005 SEAL 51 PRP96M ROLL PIN 2 X 8
6 PH7945006 SPRING 52 PH7945052 SUPPORT PLATE
8 PH7945008 O-RING 53 PH7945053 O-RING
9 PH7945009 PISTON HEAD VALVE 56 PH7945056 CONTACT TRIP BLOCK
10 PH7945010 O-RING 57 PH7945057 ADJUSTING NUT
11 PH7945011 SEAL 58 PH7945058 ADJUSTING BOLT
12 PH7945012 O-RING 59 PH7945059 SPRING
13 PH7946013 PISTON 60 PH7945060 TRIP GUIDE
16 PH7995016 DRIVER 61 PH7945061 TRIGGER
17 PH7945017 COLLAR 62 PRP98M ROLL PIN 3 X 16
18 PH7945018 CYLINDER 63 PH7945063 TRIGGER PLATE
19 PH7945019 O-RING 64 PH7945064 PLUNGER CAP
20 PH7945020 BUMPER 65 PH7945065 O-RING
21 PH7946021 SET PLATE 66 PH7945066 PLUNGER
22 PH7945022 GASKET 67 PH7945067 O-RING
23 PH7945023 NAILER BODY 68 PH7945068 SPRING
24 PH7945024 RUBBER GRIP 69 PH7945069 TRIGGER HEAD VALVE
25 PLN02M LOCK NUT M5-.8 70 PH7945070 O-RING
29 PH7945029 STEPPED PIN 71 PRP97M ROLL PIN 3 X 30
30 PH7945030 PUSHER GUIDE 72 PRP42M ROLL PIN 3 X 20
31 PH7945031 O-RING 73 PH7945073 SLIDE SHAFT
32 PH7945032 ROLLER 75 PH7945075 O-RING
33 PFH27M FLAT HD SCR M4-.7 X 5 76 PH7945076 O-RING
34 PH7945034 SPIRAL SPRING 77 PH7945077 O-RING
35 PH7995035 PUSHER 80 PH7945080 RUBBER LABEL
36 PSB139M CAP SCREW M5-.8 X 22 81 PH7945081 COVER SET PLATE
37 PSB17M CAP SCREW M4-.7 X 10 82 PH7945082 EXHAUST FILTER
38 PH7945038 NOSE COVER 83 PH7945083 SPACER
39 PSB18M CAP SCREW M4-.7 X 8 84 PH7945084 SPACER
40 PH7995040 DRIVER GUIDE PLATE 85 PH7995085 NAILER CASE
41 PH7945041 NOSE 86 PH7945086 PNEUMATIC OIL
42 PH7945042 SPRING 87 PH7995087 NAIL ASSORTMENT
43 PH7995043 CORE TRIP 88 PAW03M HEX WRENCH 3MM
44 PSBS24M BUTTON HD CAP SCR M4-.7 X 10 89 PAW04M HEX WRENCH 4MM
45 PH7945045 RUBBER PAD 90 PH7995090 PISTON REPAIR KIT
46 PH7995046 MAGAZINE 91 PH7995091 MACHINE LABEL
