53
HELP
52
DVD Audio output standards
Specifications
Power requirement AC 120V, 60Hz
Power consumption 24W (supplementary 4W)
Weight 9.9 lbs (4.5kg)
Dimensions (WxHxD) 17.1" x 3.7" x 10.0" (435mm x 93mm x 255mm)
Operating temperature 41°F~95°F (5°C~35°C)
Installation conditions Horizontal / Relative humidity under 80%
Channel coverage VHF: 2-13 CH / UHF: 14-69 CH / Cable: 1-125
Signal type NTSC COLOR
Antenna Input/output U/V-mixed: 75Ω unbalanced
VIDEO input 1.0 Vp-p unbalanced, RCA JACK
AUDIO input -8.8dBm, RCA JACK
VHF output 3 or 4 CH
VIDEO output (common use of DVD and VCR) VIDEO output terminal, 1.0 Vp-p unbalanced, RCA JACK
VIDEO output (DVD only)
S-VIDEO output (75Ω In load Y: 1.0Vp-p, C:0.286Vp-p)
COMPONENT output (75Ω In load Y: 1.0Vp-p, Pb:0.7Vp-p, Pr:0.7Vp-p)
AUDIO output (common use of DVD and VCR) Audio output terminal (2 kinds): -8.8dBm(VCR), 2.0Vrms(DVD), RCA JACK
AUDIO output (DVD only)
Analogue AUDIO output (2 CH): 2.0Vrms
Digital audio output (COAXIAL)
Playable tapes Very high dense tapes with VHS marks
Playable discs DVD, VIDEO-CD, CD (12mm), CD (8mm), MP3, CD-R, CD-RW
Tape speed SP: 33.35mm/s, SLP: 11.12mm/s
Playtime SP: 2hrs, SLP: 6hrs (use of T-120 tape)
Clock display 12 hrs AM/PM
Timer Recording 8 programs a year
VIDEO S/N (VCR) Over 45dB(Standard recording)
Resolution VCR Over 220 lines (Standard recording)
DVD Over 500 lines (DVD Disc PLAY)
AUDIO (VCR) Over 69dB (Hi-Fi), over 40dB (Mono)
AUDIO (DVD) 90dB
AUDIO dynamic range 90dB
Disc type
DVD VIDEO-CD CD
Analogue Audio output 48/96KHz sampling 44.1KHz sampling 44.1KHz sampling
Digital Audio output 48KHz sampling 44.1KHz sampling 44.1KHz sampling
Output
Troubleshooting (VCR)
• Recording a TV program is impossible.
• Once [REC] is pressed, a videotape is
ejected automatically.
• Timer recording of Cable TV does not
work.
• In spite of pressing [CHANNEL], a
channel can not be set.
• While copying, screen is distorted.
• Remote control does not work.
• Buttons on remote control do not
work.
• VISS index search does not work.
• Cable broadcasting can not be
selected.
Checks Symptom
➤ Check whether the desired channel is visible on the screen. If not,
press [OUTPUT] to view the TV.
➤ Check whether the timer recording settings are right.
➤ Are RF cables connected to the antenna connection correctly?
➤ Does a channel number appear on the display?
➤ Check the record safety tab on the videotape.
➤ Is the RF cable connected to the "ANT.IN" terminal?
➤ Make sure the clock is set correctly.
➤ Does the display show “ ” (Ready for timer recording)?
➤ Make sure the timer recording settings are right.
➤ Check the record safety tab on the videotape.
➤ Was the cable data output code set correctly?
➤ Were the converter manufacturer setup and output channel set
correctly?
➤ Did you enter a password? (Please cancel it.)
➤ Did you turn off your player? (Please turn it on.)
➤ The selected channel cannot be stored.
➤ Please check your channel settings or press a number button.
➤ Some rental tapes or discs are set to prevent copying in
manufacturing. These tapes cannot be duplicated in good condition.
➤ Battery may be weak or exhausted.
➤ If a videotape is positioned at the beginning, “VISS REW” and “REW”
do not work.
➤ If a videotape is positioned at the end, “FF”, “VISS FF”, “PLAY” and
“REC” do not work.
➤ Are you playing a tape that was not recorded in this recorder?
➤ You may have started recording in “REC-PAUSE”. Please start
recording from Stop mode.
➤ Select “CABLE” not “NETWORK” in the “CHANNEL SETTING” menu.
