GHP 10 Marine Autopilot System Installation Instructions
Dual-helm Layout Guidelines
NMEA 000 network
CCU
ECU
Pump (1. L pictured)
GHC 10
1 Vdc*
GHC 10
note: This diagram is for planning purposes only. Specific wiring diagrams are included in the detailed installation instructions for
each component. Hydraulic connections are not shown in this diagram.
* Newer ECU units are compatible with 24 Vdc systems. See page 25 for more information. * Newer ECU units are compatible with 24 Vdc systems. See page 25 for more information.
