Grizzly G0477 User Manual
Page 41
Model G0477
15" Planer/Moulder
-39-
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
201 P0477201
SPROCKET
251 P0477251
BEARING RETAINER
202 P0477202
CHAIN PROTECTOR
252 PFB14M
FLANGE BOLT M5-.8 X 12
203 PSS16M
SET SCREW M8-1.25 X 10
253 P0477253
SPINDLE WASHER
204 P0477204
ROLLER BLOCK
254 P0477254
SPROCKET
205 P0477205
ROLLER
255 PW05M
FLAT WASHER 4MM
206 P0477206
SIDE COVER (LEFT)
256 PSB23M
CAP SCREW M4-.7 X 12
207 P0477207
SIDE COVER FRAME
257 PR15M
EXT RETAINING RING 30MM
208 P0477208
SIDE COVER FRAME
258 PSS26M
SET SCREW M5-.8 X 6
209 P0477209
ELEVATING SCREW
259 P0477259
COLUMN
210 P0477210
COLUMN
260 P0477260
ELEVATING SCREW
211 P0477211
PLATEN
261 P0477261
ELEVATING NUT
212 P0477212
GUIDE ROD
262 P0477262
BUSHING
213 PSB50M
CAP SCREW M5-.8 X 10
263 P0477263
ELEVATING SCREW
214 P0477214
GUIDE
264 PFB14M
FLANGE BOLT M5-.8 X 12
215 P0477215
ROLLER PLATE (LEFT)
265 PSB24M
CAP SCREW M5-.8 X 16
216 PS07M
PHLP HD SCR M4-.7 X 8
266 PR39M
EXT RETAINING RING 8MM
217 PSB27M
CAP SCREW M6-1 X 14
267 P0477267
STEP BRACKET
218 P0477218
BUSHING
268 P0477040
STEEL BALL 6MM
219 P0477219
WAVE WASHER 10MM
269 P0477269
COMPRESSION SPRING
220 PB09M
HEX BOLT M8-1.25 X 20
270 PSS02M
SET SCREW M6-1 X 6
221 PN03M
HEX NUT M8-1.25
271 P0477271
PRESET THICKNESS STOP
222 P0477222
BASE
272 PRP01M
ROLL PIN 4 X 18
223 P0477223
EXTENSION TABLE
273 P0477273
SHAFT
224 P0477224
SUPPORT ROLLER
274 P0477274
SCALE
225 P0477225
BUSHING
275 PN07M
HEX NUT M3-.5
226 PSB68M
CAP SCREW M6-1 X 8
276 P0477276
SCALE SUPPORT
227 P0477227
SPACER
277 PS79M
PHLP HD SCR M3-.5 X 8
228 P0477228
ROLLER PLATE (LEFT)
278 P0477278
SIDE COVER (RIGHT)
229 P6000
BALL BEARING 6000ZZ
279 P0477279
STEP KNOB
230 P0477230
BEARING RETAINER
280 P0477280
TOOL BOX COVER
231 PFB14M
FLANGE BOLT M5-.8 X 12
281 P0477281
DUST CHUTE
232 P0477232
SPROCKET
282 PSB06M
CAP SCREW M6-1 X 25
233 PW05M
FLAT WASHER 4MM
283 P0477283
DUST CHUTE ADAPTER
234 PSB23M
CAP SCREW M4-.7 X 12
284 P0477284
DUST BAG
235 P0477235
IDLER BRACKET
285 P0477285
SQUARE BOX WRENCH 26MM
236 PW02M
FLAT WASHER 5MM
286 PWR810
OPEN END WRENCH 8/10MM
237 PW04M
FLAT WASHER 10MM
287 PAW04M
HEX WRENCH 4MM
238 PSB33M
CAP SCREW M5-.8 X 12
288 P0477288
MAGNET
239 P0477239
SPROCKET
289 PSB153M
CAP SCREW M5-.8 X 60
240 P0477240
BUSHING
290 PW02M
FLAT WASHER 5MM
241 PW03M
FLAT WASHER 6MM
291 P0477291
WING BOLT 1/4-20 X 1-1/4
242 PSB02M
CAP SCREW M6-1 X 20
292 PW06
FLAT WASHER 1/4
243 P0477243
CHAIN
293 P0477293
AUX GUIDE CLAMP
244 P0477244
SPROCKET
294 PN05
HEX NUT 1/4-20
245 P0477245
BUSHING
295 P0477295
SHORT GIB
246 PW03M
FLAT WASHER 6MM
296 P0477296
SPACER
247 PSB06M
CAP SCREW M6-1 X 25
297 PB02M
HEX BOLT M6-1 X 12
248 PN01M
HEX NUT M6-1
298 P0477298
SPACER
249 PB10M
HEX BOLT M6-1 X 25
299 PLW02M
LOCK WASHER 4MM
250 P6000
BALL BEARING 6000ZZ
300 PK48M
KEY 4 X 4 X 20
