GarrettCom Magnum S14 User Manual
Page 39
S14 Convenient Switches
Installation and User Guide (06/04)
32
www GarrettCom com
.
.
The side-view picture
shown here (above) is an
example of an installation of the
model MC14-TR+PS9, 19” rack-
mount tray, holding a few S14-
Series , 10Mbps FT14’s and
100Mb 14E Media Converters,
each with their power input
plugged into the built-in
common AC power supply in the
rear area of the tray. (PS units that come with the MC’s are not used).
