h6287/h6288/h6289 pallet Jacks
-7-
H6287 Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH6287001 HANDLE 50 PORP007 O-RING 6.8 X 1.9 P7
2 PRP93M ROLL PIN 6 X 25 51 PH6287051 STRIKE PIN
3 PH6287003 STEEL BALL 52 PH6287052 LEVER PLATE
4 PH6287004 COMPRESSION SPRING .7 X 4.5 X 27 53 PN01M HEX NUT M6-1
5 PH6287005 RIVET 54 PH6287054 REGULATING SCREW M6-1 X 25
6 PH6287006 JOINT BOARD 78 POR0011 O-RING 10.6 X 1.8
7 PH6287007 RIVET 80 PH6287080 O-RING 7.5 X 2.65
8 PH6287008 HANDLE 81 PH6287081 SPECIAL SCREW M8-1.25 X 1
9 PH6287009 PULL ROD 102 PH6287102 PISTON ROD
10 PH6287010 CHAIN 111 PH6287111 BIG WHEEL SHAFT
11 PH6287011 ADJUSTING SCREW M5-.8 X 40 112 P6203ZZ BALL BEARING 6203ZZ
12 PLN02M LOCK NUT M5-.8 113 PH6287113 BIG WHEEL
13 PH6287013 PRESSURE ROLLER 114 PH6287114 DUST COVER
14 PH6287014 BUSHING 115 PW27MM FLAT WASHER 17MM
15 PH6287015 ALIGNMENT PIN 116 PR18M EXT RETAINING RING 17MM
16 PR03M EXT RETAINING RING 12MM 117 PR12M EXT RETAINING RING 35MM
17 PR06M EXT RETAINING RING 16MM 118 PH6287118 SUPPORTING PLATE
18 PH6287018 PUMP PLUNGER 119 PH6287119 ELASTIC PIN 5 X 28
19 PH6287019 COVER 120 P8107 THRUST BEARING 8107
20 PH6287020 COMPRESSION SPRING 121 PW20M FLAT WASHER 35MM
21 PH6287021 DUST RING 122 PH6287122 DUST COVER
22 PH6287022 Y-RING 123-1 PB47M HEX BOLT M6-1 X 40
23 PH6287023 SHAFT 123-2 PN01M HEX NUT M6-1
25 PH6287025 PLUG 200 PSB03M CAP SCREW M5-.8 X 8
26 PH6289113 COPPER WASHER 16MM 201 PH6287201 FORK FRAME
27 PH6287027 COMPRESSION SPRING .5 X 4.8 X 21 202 PH6287202 ROCKER ARM
28 PH6287028 DAMPENING VALVE SPINDLE 203 PH6287203 ALIGNMENT PIN 14 X 30
29 PH6287029 DAMPENING VALVE SEAT 207 PH6287207 LONG SHAFT
30 PH6287030 STEEL BALL 208 PR09M EXT RETAINING RING 20MM
31 PH6287031 BASE 209 PH6287209 STRAIGHT TAPPET
32 PRP07M ROLL PIN 6 X 20 210 PR02M EXT RETAINING RING 14MM
37 PH6287037 STEEL BALL 211 PH6287211 REAR SHAFT
39 PH6287039 DUST RING 212 PH6287212 CENTER SHAFT
40 PORP028 O-RING 27.7 X 3.5 P28 213 PR36M EXT RETAINING RING 7MM
41 PH6287041 Y-RING 214 PH6287214 FORK WHEEL FRAME
43 PH6287043 STEEL BALL 215 PH6287215 FRONT SHAFT
44 PH6287044 BALL BASE 216 PR36M EXT RETAINING RING 7MM
45 PH6287045 COMPRESSION SPRING 217 P6203ZZ BALL BEARING 6203ZZ
46 PH6287046 REGULATING SCREW M10-1.5 X 1 218 PH6287218 WHEEL
47 P0464073 COPPER WASHER 10MM 219 PH6287219 AXLE
48 PH6287048 PLUG 220 PH6287220 MACHINE ID LABEL H6287
49 PH6287049 COMPRESSION SPRING 1.2 X 9.5 X 22 221 PH6287221 HANDLE POSITION LABEL
