Order codes / el.nummer
Components for distribution and mixed applications
Size of the switchboard Code / el.nummer Unit/Pack
Drilled panels
• Supplied with DIN rail complete with supports to snap onto uprights and adjustable in depth
• Available in 1 module (H 150 mm) and 1+1/2 module (H 225 mm, sizes 2-6) dimensions
• Designed to be hinged onto both vertical sides
• Snap-on mounting onto uprights (in compliance with reference Standards a tool must be used for removing the panel)
• Document pocket for storing descriptions of installed devices
1 module 1 + 1/2 module
1 1SL0307A00 / 2444367 - 1/8
2 1SL0308A00 / 2444368
1SL0313A00 / 2444371 1/8
3 1SL0308A00 / 2444368 1SL0313A00 / 2444371 1/8
4 1SL0309A00 / 2444369 1SL0314A00 / 2444372 1/4
5 1SL0309A00 / 2444369 1SL0314A00 / 2444372 1/4
6 1SL0310A00 / 2444370 1SL0315A00 / 2444373 1/2
Blank panels
• Available in 1/2 module (H 75 mm), 1 module (H 150 mm) and 2 modules (H 300 mm) dimensions
• H 150 mm and H 300 panels designed to be hinged onto both vertical sides
• Snap-on mounting onto uprights (in compliance with reference Standards a tool must be used for removing the panel)
1/2 module
1 1SL0318A00 / 2444374 1/10
2 1SL0319A00 / 2444375 1/10
3 1SL0319A00 / 2444375 1/10
4 1SL0320A00 / 2444376 1/6
5 1SL0320A00 / 2444376 1/6
6 1SL0321A00 / 2444377 1/4
1 module
1 1SL0324A00 / 2444378 1/8
2 1SL0325A00 / 2444379 1/8
3 1SL0325A00 / 2444379 1/8
4 1SL0326A00 / 2444380 1/4
5 1SL0326A00 / 2444380 1/4
6 1SL0327A00 / 2444381 1/4
2 modules
1 1SL0330A00 / 2444382 1/6
2 1SL0331A00 / 2444383 1/6
3 1SL0331A00 / 2444383 1/6
4 1SL0332A00 / 2444384 1/4
5 1SL0332A00 / 2444384 1/4
6 1SL0333A00 / 2444385 1/4
