T20644 34° Angle Finish Nailer–2½" -12 -
All nailers occasionally get jammed.
To clear a jammed nail from the dis-
charge area on the Model T20644:
1. DISCONNECT NAILER FROM THE
AIR SUPPLY!
Figure 6. Releasing quick release latch.
Figure 7. Removing driver guide cover.
Clearing Jammed
Nails
Always disconnect air from nailer
whenever clearing a jammed nail!
3. Flip up the quick release latch located
on top of the nailer nose assembly, as
shown in
Figure 6.
4. Remove the driver guide cover (Figure
7).
5. The jammed nail should now be vis-
ible; remove it from the discharge area
with needle nose pliers.
6. Replace the driver guide cover and
snap the quick release latch back into
operating position.
2. Release the magazine pusher and
slide the nail stick out of the back of
the magazine.
