11
Unit Operation
At the top left of the display you will find the Adjustment Bar and
a variety of user-selectable information including Depth, Battery Voltage,
Water Temperature, and Speed Over Water. To provide data on Water
Temperature and Speed Over Water, the Fishfinder 160 requires additional
sensors capable of producing the particular data.
The Depth Scale and the Flasher Function are displayed from top to
bottom along the right side of the display. Messages and Alarm Icons are
displayed along the bottom.
The Fishfinder 160 has three levels of display backlighting, Off, Low
and High. The backlight is activated by momentarily pressing the Power
key. To change the backlight level, press the Power key repeatedly.
If the unit is unable to track the bottom for any reason, the digits in the depth
window will fl ash on and off to alert the user that the unit is not tracking the
bottom.
Describing The Display
Adjustment Bar
Battery Voltage
Water Temperature
Speed Over Water
Depth Scale
Flasher
Alarm/Message Icons
Depth
